Replacement housing or trim part for iPod Mini 2nd Generation. Use it to restore fit, finish, color, case alignment, or visible damage rather than to fix an internal electronics fault.
Product Overview
Choose this housing listing to restore the visible fit, finish, or mounting hardware on the iPod Mini 2nd Generation.
Use the Compatible Variants table below to confirm capacity, color, or order-number fitment.
This is a fit-and-finish part, so choose it by physical damage, color, part shape, and missing hardware rather than by an electrical symptom.
What Is Included
Condition: Used factory-original part. Quantity and exclusions: The listed part, set, pair, or configuration above is supplied with exactly one plastic pry tool. No other parts, tools, adhesives, or materials are included unless they are explicitly listed above.
In the box: one top bezel and one plastic pry tool. Not in the box: adhesive. The original top bezel is stuck down with adhesive, and no adhesive is supplied with this listing. The headphone jack and Hold switch behind the trim, the two PH00 top screws that hold that assembly to the casing, the bottom bezel and the aluminum tube are all separate parts.
Quick Buying Check
Buy this when
- Use this listing when the original headphone / lock top bezel is damaged, missing, mismatched, or physically worn; diagnose internal symptoms separately.
- The original part is cracked, scratched, dented, bent, missing, loose, or cosmetically worn.
- The model, color, model-specific fitment, and capacity family match this listing.
Do not buy for
- Do not use this part for: a headphone jack that crackles or cuts out, or a Hold switch that will not latch — that is the headphone jack / hold switch assembly behind this trim, not the trim.
- Do not use this part for: the aluminum tube, the bottom dock bezel, the click wheel, logic board, battery, or storage drive.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1051 |
| EMC | EMC 2044 |
| Condition | Used — factory original Apple part. Normal cosmetic wear expected. |
| Material | Plastic |
| Color | White |
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| M9802LL/A | 4GB | Blue | — | Yes | — |
| M9806LL/A | 4GB | Green | — | Yes | — |
| M9804LL/A | 4GB | Pink | — | Yes | — |
| M9800LL/A | 4GB | Silver | — | Yes | — |
| M9803LL/A | 6GB | Blue | — | Yes | — |
| M9807LL/A | 6GB | Green | — | Yes | — |
| M9805LL/A | 6GB | Pink | — | Yes | — |
| M9801LL/A | 6GB | Silver | — | Yes | — |
Cosmetic Failure Signs — When to Replace
This housing is a cosmetic part — it does not change how the iPod plays, charges, or syncs. Replace it when the damage is physical:
| Symptom | What it means & what to check |
|---|---|
| Cracked or split white plastic | The trim splits at the corners and along the pry line — usually from an earlier opening, or from a drop onto the top end of the iPod. |
| Chewed edges and pry marks | Levering the bezel out marks the soft plastic; once the lip is deformed the trim no longer sits down flush against the aluminum tube. |
| Yellowed, dull, or stained white | Age, sunlight and handling take the white off; next to a clean tube and a fresh click wheel the difference shows. |
| Openings no longer line up | The headphone and Hold-switch cut-outs sit off-center, or the plug no longer seats squarely, after the trim was refitted crooked. |
| Bezel missing, loose, or lifting at one end | This bezel is stuck down with adhesive, so trim that keeps popping up is usually spent adhesive rather than a broken bezel. If the whole end of the case is lifting instead, read the battery row in the table below first. |
Not every buyer here is fixing damage: restoring clean white trim after another repair, bringing a gift or keepsake iPod back to presentable condition, and finishing a refreshed shell while the case is already open are just as common. The bezel is white on all four case colors — Silver, Blue, Pink, Green — so there is no color to match; what you match is the model and which end of the tube the trim belongs to.
Do Not Buy / Problems This Housing Part Does Not Fix
| Situation | Start here instead |
|---|---|
| You have a full-size hard-drive iPod with a different case design. | This is a different model — check your order number and generation before ordering. |
| The only problem is an internal electronic symptom with no physical damage to this part | Start with the diagnosis that matches your symptom — not a housing part. |
| The issue is charging, audio, storage, display, or controls rather than fit, finish, or visible housing damage | Start with the hard drive, flash storage, or drive cable check. |
| The headphone jack crackles, cuts out, or only plays one channel; the Hold switch will not latch | The trim frames those openings but the jack and Hold switch are one assembly behind it — start on the headphone jack / hold switch page. |
| The trim will not sit down, or the shell will not close flat | On this model the battery lies behind the display, so a pack that has swollen bows the internal stack, lifts the trim and can leave a dark pressure mark on the screen. New trim will not hold a swollen pack flat — start on the battery page. |
| The replacement would not match the model-specific fitment, color, or capacity family you are repairing | Confirm the exact model, capacity, connector, and case variant before ordering. |
Install Overview
Before You Start
Set Hold to locked (orange bar visible) before opening. Confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Reseat nearby ribbons and connectors before blaming a replacement housing part.
Confirm thickness, color, screw points, and nearby hardware alignment before pressing the case fully closed.
Disassembly Guide
Disassembly guide summary: iPod Mini Top Bezel Replacement.
Show all 3 installation steps
Confirm that the hold switch is locked before you open the iPod.
Carefully slide a small flathead screwdriver or Jimmy into the seam between the metal casing and white plastic top. Lever up the white top bezel, taking care not to damage the soft plastic. The top bezel is adhesive-backed, so you may need to lever it up from several spots before it releases. Heat up the adhesive for a few seconds with a hair dryer on low heat to make the job easier.
Raise the top bezel off the iPod.
Product-specific placement, reassembly, and check
- Prepare and access. Confirm the exact model and listing fit first. Use the existing steps as a disassembly guide, gather the specified tools, disconnect power where applicable, and keep screws and cable positions organized.
- Place Replacement Headphone / Lock Top Bezel. Align the jack and Hold-switch assembly with the housing openings and seat its cable without twisting or trapping it.
- Reassemble without force. Reverse only the access steps needed for this repair, keep cables clear of case edges and screw posts, and close clips in stages.
- Validate before final closure. Before final closure, test left/right audio, plug detection, and the Hold switch while the assembly remains accessible.
Stop condition: Stop if a connector, latch, screw, clip, housing edge, or the replacement part resists normal alignment. Recheck model fit, orientation, cable routing, and trapped hardware instead of forcing it.
After This Repair
| Check | What to do |
|---|---|
| Check trim fit | Confirm the trim sits flush and the port or opening is centered before final closure. |
| Still not fitting cleanly? | Recheck model-specific fitment, screw seating, and nearby clips before forcing the trim into place. |
Worth Knowing
- Top bezel houses the headphone jack and hold switch openings.
- Removal required to access internal components from the top of the aluminum tube.
- This small top trim is the plastic bezel that frames the headphone jack and lock-switch openings.
- This is the second-generation Mini top-bezel listing — sold in a single-bezel pack with the pry tool included, not a multi-part kit.
- The bezel is white on every case color — Silver, Blue, Pink and Green — so there is no color to match; what you match is the model and which end of the tube the trim belongs to.
- The top bezel fits either iPod mini generation. Both minis use the same A1051 case and the same white trim, and replacement bezels are listed for the first and second generation alike by two independent sellers. The trim is not the only mini part that carries over, but three parts do not: the click wheel (its connectors are a different size), the display and the logic board — keep those with the iPod they came from.
- It is held on by adhesive rather than clips or screws, which is why the disassembly step warms it before levering — and why a bezel that will not stay down is usually spent adhesive rather than a broken part.
- Lift this bezel and you are at the two PH00 screws that hold the headphone-jack board to the casing; those are a separate two-screw set if yours are missing or rounded.
Frequently Asked Questions
How do I choose the right cosmetic part?
Match the model generation first, then confirm capacity 4GB / 6GB and that you need the top bezel — the headphone and Hold-switch end — rather than the bottom dock bezel. The bezel is white on all four case colors — Silver, Blue, Pink, Green — so there is no color to match.
Is this for a full-size hard-drive iPod?
The iPod mini is a separate Apple product line from full-size hard-drive iPods. This is the iPod mini 2nd Generation.
Will this fix internal electronics symptoms?
No. Housing and trim parts are for fit, finish, color, alignment, or visible damage. Diagnose power, storage, audio, screen, and control faults separately.
How do I confirm this is the right exterior part?
Match the exact iPod Mini 2nd Generation model, visible part shape, color or finish goal, and any capacity or model-specific fitment note before ordering Replacement Headphone / Lock Top Bezel.
Will this bezel fit a first-generation iPod mini?
Yes. Both mini generations use the same A1051 case and the same white trim, and replacement bezels are listed for the first and second generation alike. The trim carries over; three parts do not — the click wheel (its connectors are a different size), the display and the logic board — keep those with the iPod they came from.
