Cosmetic Select/center-button cap only — no electronics. Swap for color or a cracked/worn cap. Will not fix a button that clicks but doesn't register.
Product Overview
Choose this center button listing to restore the visible fit, finish, or mounting hardware on the iPod Classic 6th Generation.
Use the Compatible Variants table below to confirm capacity, color, case, or order-number fitment.
This is a fit-and-finish part, so choose it by physical damage, color, case thickness, and missing hardware rather than by an electrical symptom.
This can also be a customization choice. Control assemblies and center buttons may be offered in custom non-OEM finishes, so buyers may replace working controls for a coordinated custom build as long as the control fitment matches the model.
What Is Included
Quick Buying Check
Buy this when
- Center / Select button or specific control failure: People describe behavior that can point toward the center button, but the symptom does not prove this part has failed.
- Center Button appears unresponsive or intermittent: People describe behavior where the center button seems dead, intermittent, or only partly responsive.
Diagnose first when
- Compare the exact behavior, when it started, and whether it changed after a repair.
- Inspect nearby cables and connectors before replacing major parts.
- Inspect nearby connectors and flex paths if the iPod has been opened.
- Diagnose first — audio/lock or lock state symptoms: The iPod appears locked or the audio/lock does not match the device behavior. This symptom family points to a different part, not the center button cap.
Do not buy for
- Do not use this part for: Control assembly, control assembly flex cable, rubber dome, or board-side tactile switch faults.
- Do not use this part for: Custom-color center button orders - use the custom center-button page.
- Check nearby parts first when the symptom is tied to another assembly or appeared after unrelated work.
- If the whole wheel is unresponsive, check the control assembly, headphone/Hold assembly, and logic-board contact check before the button cap.
- Other center-button colors - choose the matching cap for silver-front models.
Other Symptoms That May Involve This Part
| Symptom | What it means & what to check |
|---|---|
| Red X | This is a storage-path symptom. Check the hard drive, hard-drive cable, and flash-mod storage path. |
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1238 |
| EMC | EMC 2173 |
| Condition | New replacement center button |
Customization Options
Compatible Variants
| Order Number | Capacity | Case | Compatible | Notes |
|---|---|---|---|---|
| MB147LL/A | 80GB | thin (0.41 in) | Yes— color swap | Fits any iPod Classic 6G; the color differs from that unit's original look. |
| MB029LL/A | 80GB | thin (0.41 in) | Yes— original color match | Other center-button colors - choose the matching cap for silver-front models |
| MB565LL/A | 120GB | thin (0.41 in) | Yes— color swap | Fits any iPod Classic 6G; the color differs from that unit's original look. |
| MB562LL/A | 120GB | thin (0.41 in) | Yes— original color match | Other center-button colors - choose the matching cap for silver-front models |
| MB150LL/A | 160GB | thick (0.53 in) | Yes— color swap | Fits any iPod Classic 6G; the color differs from that unit's original look. |
| MB145LL/A | 160GB | thick (0.53 in) | Yes— original color match | Other center-button colors - choose the matching cap for silver-front models |
| MC297LL/A | 160GB (Late 2009) | thin | Yes— color swap | Fits the Late-2009 thin 160GB (MC293LL/A / MC297LL/A); that model is sold under the iPod Classic 7th Generation (Late 2009) pages. |
| MC293LL/A | 160GB (Late 2009) | thin | Yes— compatible | Thin-Classic cosmetics/framework interchange; the Late-2009 thin 160GB (MC293LL/A / MC297LL/A) is sold under the iPod Classic 7th Generation (Late 2009) pages |
Cosmetic Failure Signs — When to Replace
This center button is a cosmetic part — it does not change how the iPod plays, charges, or syncs. Replace it when the damage is physical:
| Symptom | What it means & what to check |
|---|---|
| Worn, shiny, or discolored button face | The center button takes the most presses on the whole iPod; the surface wears smooth and shiny long before it stops working. |
| Cracks or chips | Physical damage to the button surface, usually after a drop on the wheel side. |
| Color mismatch after other cosmetic work | A faceplate or control-face refresh can leave the original button as the one part that no longer matches. |
Not every buyer here is fixing damage: matching the original silver finish after another repair, restoring a gift or keepsake iPod to clean condition, and finishing a refreshed shell while the case is already open are just as common.
Do Not Buy This Part Yet If...
| Situation | Start here instead |
|---|---|
| A symptom points to a different part | Start with the neighboring part or diagnostic that matches your symptom (storage, cable, battery, screen, audio, or board) before buying this part. |
| Cable, computer, sync, or port behavior is the primary problem | Start with the USB cable, 30-pin dock connector, and host checks for your model before buying this part. |
| You see a folder icon, clicking noise, or restore failure | Confirm restore behavior, storage fit, and setup state before ordering this part. |
| Charging, swelling, runtime, or power is the primary problem | Confirm power, charging, and pack-condition clues before replacing this part. |
| Only the screen is affected and everything else works | Check the display path and cable seating before replacing this part. |
| Recent service or connector disturbance is the main clue | Use this part only when the visible fit, finish, or physical damage matches. |
Check These Nearby Mechanisms First
This part may sit near or press against rubber dome, rubber pad, tactile membrane, or microswitch. Those are separate parts sold on their own pages — if your symptom traces to one of them, check that part before ordering this one.
board-side tactile switch or logic-board switch points to logic-board or professional board-level service; the Replacement Center Button (Silver) alone will not repair that mechanism.
Install Overview
Before You Start
Power down, use the reset sequence for this generation, and confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Check nearby connectors before blaming a replacement part.
Confirm thickness, color, screw points, and nearby hardware alignment before pressing the case fully closed.
Handle damaged, hot, punctured, or suspect batteries as a safety issue. Do not charge them or continue a repair until the battery condition is understood.
Repair Guide
Repair guide summary: iPod Classic Center Button Replacement.
Show all 30 installation steps
This iPod case is unusually hard to open without damaging major components. Its metal faceplate, metal backing, and thirteen metal clips make disassembly especially demanding. Caution: this opening method can significantly damage the iPod beyond its current condition. Keep a few extra plastic opening tools nearby, since they are easy to ruin while opening the case. Confirm the device is powered down before you open the iPod.
Opening this iPod is challenging, so do not get discouraged if it takes a few tries. Watch the plastic opening tool tip angle as you insert it into the iPod; keep it as vertical as possible while still clearing the rear panel edge. Guide a plastic opening tool into the seam between the front and rear of the iPod.
Slide a second plastic opening tool into the seam between the iPod front and rear, keeping the two tools at least 1.5 inches apart.
Working at an angle, carefully slide a putty knife about 1/8 inch into the gap between the two opening tools. You will find thin metal rails running along the inside of the back panel, so work very carefully when inserting the putty knife. After the putty knife clears the rear panel lip, rotate it vertical and carefully but firmly work it straight down through the opening tool gap.
Press on the rear panel behind the putty knife with your fingers to reduce bending. Slowly flex the putty knife so most metal tabs along this side of the iPod release. The idea is to control how the rear panel bends instead of trying to prevent all bending. Any side bend should draw the rear panel lip away from the iPod, not push outward on the curved surface. This also releases as many side clips as possible.
Take the putty knife out, then place it closer to the iPod corner and use the same gentle wiggle method. If possible, do not bend the rear panel corner.
Near the headphone jack, guide a plastic opening tool into the seam between the front and rear of the iPod. It may be easier to flex the putty knife downward carefully to create more room for the opening tool. Be careful not to bend the rear panel corner.
Near the display center, carefully slide a metal spudger into the gap made by the plastic opening tool. A visible bump can form here in the rear panel and is hard to repair. When levering the tab free, pivot the metal spudger on the rear panel edge instead of bending the rear panel outward. With the metal spudger, release the single clip at the iPod top edge.
Near the other top corner, guide a plastic opening tool into the seam between the front and rear of the iPod
On the other side, use the opening tool to start the same case-opening gap. It may help to angle the tool stuck in the top corner to create enough room.
Take the opening tool out of the top corner, then slide it into the seam between the iPod front and rear. Keep at least 1.5 inches between the two tools, as on the opposite side.
Working at an angle, carefully slide a putty knife about 1/8 inch into the gap between the two opening tools. Again, you will find thin metal rails running along the inside of the back panel, so work very carefully when inserting the putty knife. After the putty knife passes the rear panel lip, turn it vertical and carefully but firmly work it straight down through the gap between the plastic opening tools. Press on the rear panel behind the putty knife with your fingers to reduce bending. Flex the putty knife just enough to make sure most metal tabs along this side of the iPod release.
The metal clips near the corners grip the front panel tightly. Release these clips before opening the iPod. Carefully slide a metal spudger into the area beside the stubborn metal clip.
Gently work the metal spudger downward until it is fully seated in the rear panel.
Gently start releasing the clip from the front panel. A visible bump can form here in the rear panel and is hard to repair. When levering the tab free, pivot the metal spudger on the rear panel edge instead of bending the rear panel outward.
Use the metal spudger to apply upward pressure under the front panel until the metal clip releases.
You will find two cables connecting the rear panel to the remaining iPod assembly. In the following step, take care not to damage these cables. In this step, grasp the front-panel assembly with one hand and the back panel with the other. Pause for a moment before continuing. Very gently release the remaining rear-panel clips by pulling the tops of the front and rear panels apart, using the iPod bottom as a hinge. Take great care not to damage the cables joining the two halves.
With a spudger, slide the connector upward where it holds the orange battery cable. Lift the locking bar only about 2 mm to release the cable. Move the orange battery cable out of its connector.
Set the rear panel beside the iPod, taking care not to strain the orange headphone jack cable.
Raise the hard drive with one hand to expose the headphone jack cable underneath. With a spudger, flip up the plastic tab securing the headphone jack cable in place. The tab can rotate up 90 degrees, releasing the cable. Move the orange headphone jack cable out of its connector. The rear panel is now released from the iPod.
After opening, check the lower-case clips. If any clip bent upward, press it back down gently so the rear case can close cleanly.
Use the broad, flat face of the metal spudger to press the clip downward. Work carefully so the thin metal rail does not tear away from the rear panel. While shaping these clips, take care not to damage any headphone jack parts.
Set the rear panel on its side on a clean, hard surface. Carefully but firmly press it downward, rolling the full lip edge back into place. You may need to repeat this several times to straighten the sides well. Slightly overcorrecting the case edges inward is better than leaving them too far out, because reseating the front panel will bend the rear panel back into alignment. Once the rear panel is restored to good condition, continue with the iPod repair.
Rotate the hard drive out of the framework, then set it with the connector facing upward. With a spudger, lift the small black locking tab for the orange hard drive cable. The tab rotates upward 90 degrees and frees the cable.
Move the orange hard drive cable straight out of its connector. Keep the drive's rubber mounting brackets and foam padding in place for reassembly.
Take out the three Phillips screws that secure the front panel to the metal framework.
Rotate the iPod 180 degrees and take out the 3 Phillips screws holding the front panel to the metal framework on the other edge.
In this step, gently work around the edges of the device to separate the front panel from the gray metal framework. You may meet some resistance, as you will find a mild adhesive used to help hold the two parts together.
Lift the full framework away from the front panel; it carries the screen, logic board, and control assembly. Confirm the center button cap is seated before reinstalling the framework in the front panel.
Take out the center button cap from the iPod.
After This Repair
| Check | What to do |
|---|---|
| Test every control | Check that the cap sits flush, returns cleanly, and matches the surrounding front-panel fit before closing the case fully. |
| If controls are still odd | Reseat the control cable, confirm the audio/lock is off, and inspect any ground strap or latch touched during service. |
Frequently Asked Questions
How do I choose the right cosmetic part?
Match the model generation first, then confirm capacity 80GB / 160GB / 120GB / 160GB (Late 2009) and color Silver, clip layout, and nearby hardware before ordering.
Will this fix internal electronics symptoms?
No. Housing and trim parts are for fit, finish, color, alignment, or visible damage. Diagnose power, storage, audio, screen, and control faults separately.
How do I confirm this is the right exterior part?
Match the exact iPod Classic 6th Generation model, visible part shape, color or finish goal, and any capacity or case-depth note before ordering Replacement Center Button (Silver).
Does color change physical fitment?
Color alone does not block fitment when the same model, generation, and part shape match. It will only change the visible finish.
What does this part not fix?
This part does not fix power, storage, display, audio, or board faults. Use it for visible damage, missing trim, fitment, or cosmetic refresh after diagnosis points away from electronics.
Worth Knowing
- The control assembly is retained by four small tabs — a wheel falling out of the faceplate usually means bent tabs; check them during reassembly.
- Owners report a quick isolation test: push-buttons respond but touch-scroll does not — wheel side; neither responds — connector or board side.
- Owners report a frozen unit showing one static song is a reset case — hard reset before replacing controls.
Why people land on this part
Also searched as: battery not charging, charging problem, clicking hard drive, Non-clicking center button, iPod classic 6th gen silver center button, center button stuck, Center button doesn't pop back up, Center button feels mushy, Center button felt odd, Center button gave up, Center button is stuck in the pressed condition, iPod classic sixth generation silver center button repair service, iPod classic sixth generation silver center button replacement guide, iPod classic sixth generation replacement silver center button kit, center cap, enter button, black center button, center button not responding, select button unresponsive, Buttons not working, center button clicks but does not work, Center button doesn't work and no Apple logo appears.
Some buyers search for "loose", "scratched", "dented", or "mismatched"; confirm the checks above point to this same part before ordering.
