Replacement bottom dock bezel for iPod Classic 6th Generation shells. Use it when the small plastic trim around the 30-pin opening is cracked, broken, missing, loose, dirty, or mismatched after matching case depth and bezel color.
Product Overview
Use this listing for an iPod classic dock connector bezel, dock bezel, dock connector spacer, dock spacer, bottom bezel, dock plastic, dock connector trim, or dock port bezel on an iPod Classic 6th Generation.
This is NOT the 30-pin dock connector. The bezel is cosmetic plastic trim. It does not fix charging, sync, or connection problems.
Choose by case depth first and bezel color second. Thin 80GB, 120GB, and Late 2009 160GB shells use the thin bezel; the original 2007 160GB shell uses the thick bezel. Black and white bezels are mechanically identical, so the color choice is about stock appearance or a deliberate custom color.
- Initialize disk format: HFS Plus (Mac) or FAT32 (Windows)
- Apple logo stuck may be caused by macOS HFS+ format incompatibility
What Is Included
Quick Buying Check
Buy this when
- The small bottom bezel around the 30-pin opening is cracked, broken, missing, loose, stained, or cosmetically mismatched.
- You are refreshing the bottom trim during a backplate or exterior rebuild after confirming thin or thick case depth.
Check before ordering
- Measure the rear case depth: thin is 10.5 mm / 0.41 in, and thick is 13.5 mm / 0.53 in.
Do not buy for
- Charging, sync, or connection faults. Those point to the 30-pin dock connector, cable, adapter, or board diagnosis, not this plastic trim.
- A damaged LCD, click wheel, battery, headphone jack, Hold switch, or rear backplate.
What Brings People Here
Cracked bottom trim
The plastic dock bezel is cracked around the 30-pin opening or chipped from case opening.
Missing bezel
The small bottom spacer is gone, leaving the dock opening unfinished or uneven.
Loose or dirty trim
The bezel no longer sits cleanly or is too worn and dirty for a refreshed exterior.
Backplate service
Buyers often replace the bezel while the rear panel is already open for housing work.
Stock color match
White trim pairs with silver-front builds; black trim pairs with black-front builds.
Custom color build
Because the colors are mechanically identical, a bezel color can also be selected for a deliberate custom look.
Color + Depth Selection
| Case depth | Front color | Bezel color | Order numbers |
|---|---|---|---|
| Thin (80GB/120GB/Late 2009 160GB) | Silver | White | MB029LL/A, MB562LL/A, MC293LL/A |
| Thin (80GB/120GB/Late 2009 160GB) | Black | Black | MB147LL/A, MB565LL/A, MC297LL/A |
| Thick (original 2007 160GB) | Silver | White | MB145LL/A |
| Thick (original 2007 160GB) | Black | Black | MB150LL/A |
Measure case depth before ordering: thin = 10.5 mm / 0.41 in; thick = 13.5 mm / 0.53 in.
Black and white bezels are mechanically identical and interchangeable - choose by aesthetic preference or stock-appearance match.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1238 |
| EMC | EMC 2173 |
| Condition | Used — factory original Apple part. Normal cosmetic wear expected. |
| Part type | Plastic dock bezel trim |
| Selection axis | Case depth first, bezel color second |
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| MB147LL/A | 80GB | Black | thin (0.41 in) | Yes— stock match | — |
| MB029LL/A | 80GB | Silver | thin (0.41 in) | Yes— stock match | — |
| MB565LL/A | 120GB | Black | thin (0.41 in) | Yes— stock match | — |
| MB562LL/A | 120GB | Silver | thin (0.41 in) | Yes— stock match | — |
| MB150LL/A | 160GB | Black | thick (0.53 in) | Yes— stock match | — |
| MB145LL/A | 160GB | Silver | thick (0.53 in) | Yes— stock match | — |
| MC297LL/A | 160GB | Black | thin | Yes— compatible | Stock match |
| MC293LL/A | 160GB | Silver | thin | Yes— compatible | Stock match |
When This Dock Bezel Helps
Cracked plastic trim
Replace the bezel when the visible bottom plastic around the dock opening is cracked, split, or broken.
Missing bottom spacer
A missing bezel leaves the dock opening unfinished and can make a restored case look incomplete.
Loose or warped bezel
The trim should sit flush after the case is reassembled; warped plastic is a cosmetic housing issue.
Dirty or worn plastic
Deep staining, grime, or worn texture can justify replacing the bezel during a cosmetic refresh.
Color mismatch
Use white or black trim to match the chosen front color, or choose a contrast intentionally for a custom build.
Backplate rebuild
The bezel is often handled during rear-panel service, so it is a small trim part to check before closing the shell.
- Measure battery voltage with voltmeter - a dead battery often reads 0V
- Note: checking a battery with a multimeter is unreliable because the battery may show adequate voltage but fail under load.
- Check fuse F1 for continuity with multimeter
Do Not Buy This Dock Bezel Yet If...
| Situation | Start here instead |
|---|---|
| The iPod will not charge, sync, or connect reliably | Use the 30-pin dock connector page or a free diagnostic. The bezel is plastic trim only. |
| The 30-pin pins are bent, loose, broken, or corroded | That is the soldered dock connector, not this cosmetic bezel. |
| You have not checked thin versus thick case depth | Measure the shell before ordering. Thin and thick bezels are different. |
| Only the chrome rear panel is damaged | Use the backplate selector and match rear case depth there. |
| The battery, LCD, click wheel, headphone jack, or Hold switch is damaged | Those are separate parts and will not be fixed by bottom plastic trim. |
Install Overview
Dock-bezel replacement is mechanically simple after the iPod is open: the bezel is held by two Phillips screws. The difficult part is opening the Classic shell without bending the rear panel or damaging ribbons.
Case opening risk
Difficult. The Classic shell uses 13 metal clips, and opening often marks or bends the rear panel.
Battery safety
Disconnect the battery before working near the bottom opening. Stop if the cell is swollen, hot, or punctured.
Two-screw trim part
Once the rear panel is open, the dock bezel is a small plastic trim piece secured by two Phillips screws.
Confirm before closing
Check that the bezel sits flush, the dock connector is centered in the opening, and the rear shell closes without pinching cables.
Repair Guide
| Reference | Use it for |
|---|---|
| Battery access guide | Opening the Classic shell and disconnecting the battery before reaching bottom trim. |
| Rear panel access guide | Rear-panel teardown context before removing bottom trim hardware. |
There is no dedicated dock-bezel guide for this exact trim piece. Use the battery or rear-panel guide for safe case access, then remove the two bezel screws once the bottom trim is reachable.
After This Repair
| Check | What should be true |
|---|---|
| Bezel fit | The trim sits flush and does not rattle. |
| Dock opening | The 30-pin connector is centered in the bezel opening. |
| Case closure | The rear shell closes without gaps near the bottom edge. |
| Screw seating | Both bezel screws are snug, not stripped or over-tightened. |
Frequently Asked Questions
Is this the dock connector?
No. This is the plastic dock bezel around the 30-pin opening. It does not repair charging, sync, recognition, or connection faults.
How do I know if I need the thin or thick bezel?
Measure the rear case depth. Thin shells are 10.5 mm / 0.41 in; the original 2007 thick 160GB shell is 13.5 mm / 0.53 in.
Is the dock bezel the same as a case or bumper?
No. The dock bezel is the internal plastic trim around the 30-pin opening, not an external case, cover, or bumper.
Does replacing the bezel require soldering?
No. The bezel is held by two Phillips screws after the case is open. The separate 30-pin dock connector is the soldered part.
Worth Knowing
- This is cosmetic bottom trim only; it is separate from the soldered 30-pin dock connector.
