Replacement internal cable for iPod 4G Monochrome. Use it when the flex or ribbon is torn, creased, loose, or failing at the connector before blaming the whole attached assembly.
Product Overview
This cable listing covers Hard Drive IDE Ribbon Cable and its own connector path on the iPod 4th Generation (Monochrome).
Use Part Details for the confirmed part-number reference. Use the Compatible Variants table below to confirm capacity, color, case, or order-number fitment.
Choose this part when your iPod shows Sad iPod Icon, Folder Icon, Clicking Noise, or Red X Icon; the checks below help confirm the right part before you order.
- The Toshiba MK8007GAH 80GB is a compatible upgrade drive
- A compatible upgrade option is the Toshiba MK8007GAH (80GB), which uses the correct ATA-6 pin interface.
- Error 1429 typically indicates a hard drive problem
- Compatible Toshiba drives end in 004 or 006 (MK4004GAH, MK2006GAL, MK2006GALC, MK3006GAL, MK4006GAL)
- Use a USB-to-ZIF adapter cable to test the hard drive externally on a computer
- If restore fails, format the hard drive via Windows: right-click iPod in My Computer and select Format
- Test the hard drive externally with a USB adapter to verify functionality
- Coconut Battery is a Mac utility that can provide diagnostic information about the iPod battery's health
- Put iPod in Disk Mode and format as Mac OS Extended (Journaled) if Restore fails
What Is Included
Quick Buying Check
Buy this when
- Hard Drive Failure: Use the cable check when reseating, connector inspection, or a known-good drive points to the storage ribbon instead of the drive itself.
Diagnose first when
- Confirm thin or thick case thickness before ordering battery, hard drive, cable, or rear case parts.
- Try a known-good cable, charger, and computer port before opening the iPod.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1059 |
| EMC | EMC 1995 |
| Condition | Used — factory original Apple part. Normal cosmetic wear expected. |
| Interface | Toshiba 1.8-inch IDE/PATA flex |
| Type | Flat ribbon cable |
| OEM Part |
632-0259, 632-0259-A
|
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| M9787LL/A | 20GB | Black/Red (U2) | thin | Yes | — |
| M9282LL/A | 20GB | White | thin | Yes | — |
| PE435A | 20GB | White (HP) | thin | Yes | — |
| M9268LL/A | 40GB | White | thick | Yes | — |
| PE436A | 40GB | White (HP) | thick | Yes | — |
Diagnostic Failure Cards
Use these model-specific failure cards to decide whether this cable is the right part, a nearby part needs checking first, or escalation makes more sense after simpler checks.
Check before ordering
Restore, sync, setup, or frozen-state symptoms
What you may notice
- People describe restore loops, sync trouble, frozen screens, language/setup screens, or diagnostic states that make a part look suspect.
Diagnose first when
- Separate a one-time software or restore state from a repeatable hardware symptom.
- Check whether the symptom changes in disk mode, diagnostic mode, or after a supported reset.
- If the state appeared after part replacement, inspect the related ribbon and connector before buying again.
- Reseat both ends of the storage ribbon and inspect the connector or latch before replacing the cable.
Similar issues to separate
- Choose this cable only when the same hardware symptom repeats outside the temporary device state.
Where this cable does not fit
Check another part first
- Check storage, battery power, input state, and connector seating first when the symptom is tied to restore or setup.
Repair or replacement paths
- Replace the cable when the symptom follows that part across normal use and restore/setup states.
- Continue software, storage, power, or input diagnosis when the symptom appears only during setup or restore.
Sad iPod, clicking, restore, or storage trouble
What you may notice
- People describe clicking, sad iPod or folder screens, restore loops, disk-mode trouble, or storage that will not behave after replacement.
- Sad iPod, red X, clicking drive, restore loop, or disk-mode trouble.
Diagnose first when
- Confirm thin or thick case thickness before ordering battery, hard drive, cable, or rear case parts.
- Listen for repeat clicking or repeated spin-up attempts before replacing storage parts.
- Check whether the iPod enters disk mode, restores cleanly, and is recognized by the computer.
- If a drive or flash adapter was just installed, recheck cable seating, adapter orientation, and formatting before buying another part.
Similar issues to separate
- The 4G comes in thin 20GB and thick 40GB case variants. Battery, hard drive, and backplate fitment can differ by case thickness.
- The cable can be involved, but the drive cable, adapter formatting, power stability, or logic-board storage path may also be responsible.
- Check storage / restore route, connector seating, and board-side damage before ordering.
- Choose this cable only when clicking, restore failure, or disk errors follow this part or its connection path.
- Choose this cable when the symptom remains isolated to this assembly, its ribbon, or its connector path after first checks.
Check another part first
- Check the storage cable, adapter setup, battery power stability, and board connector when the symptom changes after reseating or swapping storage.
Repair or replacement paths
- Replace the cable only when the storage or restore symptom is tied to this part's role in the startup path.
- Use cable, adapter, or board diagnosis first when restore behavior changes with seating, formatting, or another known-good storage device.
- Advanced or board-level cases
Cable ribbon, connector, or contact path
What you may notice
- People describe symptoms that change after opening the iPod, reseating parts, or disturbing nearby flex cables.
- A symptom starts after opening the iPod or disturbing an internal flex cable.
Diagnose first when
- Inspect the relevant ribbon and board connector before replacing the part.
- Look for lifted latches, bent contacts, debris, corrosion, creases, or torn flex material.
- Check whether the symptom changes after careful reseating.
Similar issues to separate
- The cable may be fine while its ribbon, connector, latch, or contact path is loose, dirty, damaged, or not fully seated.
- Connector seating, ribbon damage, or ground-path issues can involve this part, a nearby connector, or a board path.
- Choose this cable only when the part's own flex or contact path is damaged.
Check another part first
- Check the board-side connector or adjacent cable first when the damage is not on the replaceable assembly.
Repair or replacement paths
- Reseat or clean only where the repair procedure supports it.
- Replace the cable when the flex, connector tail, or assembly contact path is physically damaged.
Dock, USB, sync, or charging connection trouble
What you may notice
- People describe charging, USB recognition, sync, or dock-connector behavior that is intermittent or missing.
Diagnose first when
- Try a known-good cable, charger, and computer port before opening the iPod.
- Inspect the dock connector for debris, bent pins, corrosion, or looseness.
- Separate charging-only failure from computer-recognition or sync failure when choosing a part.
Similar issues to separate
- Choose this cable only when charging, sync, or dock behavior is tied to this part or its connector path.
Check another part first
- Check cable, charger, battery, storage restore state, and board condition when the dock path is not clearly isolated.
Repair or replacement paths
- Replace the cable when inspection points to this part's role in the dock, USB, sync, or charging path.
- Continue battery, storage, or board diagnosis when the port looks healthy but power or sync still fails.
Fitment and post-repair traps
Symptoms changed after repair or reassembly
What you may notice
- People describe a new problem appearing immediately after battery, storage, display, audio, or control work.
- A new symptom appeared after battery, storage, audio, display, or control work.
Diagnose first when
- Reopen only as far as needed to inspect the areas touched during the repair.
- Compare the new symptom with what worked before the repair.
- Check cable seating, latch position, and part variant before replacing a second part.
Similar issues to separate
- A post-repair symptom can involve the cable, but disturbed ribbons, latches, grounding, connector seating, or the wrong variant part are common checks before ordering again.
- Check post-repair regression, connector seating, and board-side damage before ordering.
- Choose this cable only when the part itself was torn, creased, or damaged during service.
Check another part first
- Check the exact connector or assembly disturbed during the repair before treating the new part as failed.
Repair or replacement paths
- Correct seating, latch, or variant problems first.
- Replace the cable when the repair damaged that assembly or its flex path.
Fitment or model-variant mismatch
What you may notice
- People ask whether a similar-looking part from another capacity, case thickness, or generation will work.
Diagnose first when
- Match the exact model, generation, capacity, and case style shown for the product.
- Do not use a symptom to override fitment: a wrong-variant part can create new symptoms after installation.
Similar issues to separate
- This cable may help only when it matches the model and variant being repaired.
Check another part first
- Check fitment before replacing nearby parts or ordering another copy of the same wrong variant.
Fitment and inspection notes
Symptom remains after basic checks
What you may see: The iPod still points back to Hard Drive IDE Ribbon Cable after cable seating, battery stability, and nearby connector checks.
Check first: Retest with known-good cables or adjacent parts where practical before ordering.
Check next: A nearby cable, connector, battery, storage device, display path, audio path, or board path can mimic a bad cable.
Symptom changes when touched or reseated
What you may see: The symptom changes after moving the part, reseating a cable, or applying light pressure near the connector path.
Check first: Inspect the connector, latch, flex, solder joints, and nearby board area for damage or corrosion.
Check next: This can still be a connection issue rather than a failed cable alone.
Problem began after another repair
What you may see: The issue started immediately after opening the iPod, replacing another part, or disturbing an internal cable.
Check first: Reopen only as far as needed and inspect the exact area touched during the previous repair.
Check next: Post-repair symptoms often trace to seating, latch, screw, or cable issues before Hard Drive IDE Ribbon Cable itself is confirmed bad.
Repair considerations
Repair specialists who work on this model consistently flag these checks before replacing the cable — they help confirm the cable is the right fix and not a nearby fault:
- Restore/format steps can erase data or indicate storage failure
- Treat ribbons, tabs, and connectors as fragile
- Use reset, Disk Mode, restore, or iTunes/Finder behavior as a software/storage check
- Inspect connector latch, socket, or clamp condition
- Reseat or inspect ribbon cable and connector seating
- Check drive noise, SMART/data signs, or storage recognition
Do Not Buy / Problems This Cable Does Not Fix
| Situation | Start here instead |
|---|---|
| Variant or capacity does not match this listing | This is a different model — check your order number and generation before ordering. |
| Cable, computer, sync, or port behavior is the primary problem | Inspect and reseat the cable, latch, or connector path disturbed during service before buying another part. |
| The problem is the Hold switch or headphone jack, not this part | Use the port, cable, host, or power path if the storage ribbon is not the isolated fault. |
| You see a folder icon, clicking noise, or restore failure | Confirm restore behavior, storage fit, and setup state before ordering this part. |
| Recent service or connector disturbance is the main clue | Check the matching drive, cable seating, and board-side connector before ordering. |
| A symptom points to a different part | iPod 5th Gen Video / 6th Gen / 7th Gen — uses connector ribbon cable, not IDE/ATA. |
- The 4th generation uses a DDKLtd MCD-D50SA-3 connector (pin-style)
- Most USB-to-ZIF adapters include multiple adapters for different connector types
- Compatible Toshiba drives include models ending in 004 or 006, such as: - MK4004GAH - MK2006GAL - MK2006GALC - MK3006GAL - MK4006GAL The 4th generation uses a DDKLtd MCD-D50SA-3 connector (pin-style).
- The selected drive is not compatible.
Install Overview
Before You Start
Turn Hold off, use the reset sequence for this generation, and confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Reseat nearby ribbons and connectors before blaming a replacement cable.
Verify the exact generation, capacity/thickness variant, connector, and part listing before ordering; similar-looking iPod parts are not always interchangeable.
Check drive-ribbon seating and bumper placement while the iPod is open.
Repair Guide
Repair guide summary: iPod 4th Generation or Photo Hard Drive Cable Replacement.
Show all 8 installation steps
Before you open the iPod, confirm that the hold switch is in the locked setting. The orange bar should be showing, indicating hold is active.
Move an opening pick as far as possible into the gap between the plastic front and the metal back panel, on the right edge of the iPod. You may have to rock the pick back and forth to move it in farther. With the opening pick, lever up against the plastic front panel and release 5 retaining tabs. Slide the pick along the iPod edge and keep levering gently until the remaining retaining tabs release. In this step, after all five tabs along the right edge are free, the case should easily open.
The iPod case is now open, but do not separate the two halves yet. An orange ribbon cable still connects the headphone jack to the logic board. With the dock connector edge at the top, open the case like a book and set the rear panel beside the iPod front half.
With a plastic tool or your fingernails, carefully detach the orange headphone jack cable. Make sure to draw straight up on the connector, not the cable itself. This fragile ribbon cable can stay connected for a battery replacement. Prop and tape the rear case against a box so the headphone jack remains connected to the motherboard without straining its cable while you work.
Grasp the hard drive with one hand and carefully detach the orange ribbon cable from the hard drive with your other hand. In this step, if the cable doesn't come free easily, it may be useful to gently wiggle the cable from side to side.
Peel up and back the black adhesive strip covering the hard drive ribbon cable.
With a fingertip or spudger, carefully flip up the black hard drive cable connector on the logic board. The black retaining clip rotates 90 degrees toward vertical in the cable direction.
Draw the orange hard drive cable directly out of its connector.
After This Repair
| Check | What to do |
|---|---|
| Test the connected part | Confirm the assembly on both ends of the cable behaves normally before closing the iPod. |
| Still not working? | Inspect the latch, cable orientation, and board-side connector before replacing another part. |
Worth Knowing
- Same cable fits both thin (20GB) and thick (40GB) case variants.
- Cable runs between the hard drive and the logic board — prone to damage during case opening.
- The sad iPod icon typically indicates a hard drive failure
- Wait 30 minutes while the iPod is charging.
- Clicking or hard drive whirring sounds indicate a hard drive problem
- Clicking sounds are a common precursor to hard drive failure in iPods
Frequently Asked Questions
Use these questions to narrow the part path before ordering. They keep each answer focused on a different diagnostic or fitment decision.
How do I choose the right hard-drive cable?
Match the exact storage path for this model. Some cables depend on drive brand, case depth, or connector style, not just the iPod generation.
When is the cable more likely than the drive?
A cable becomes more likely when it is torn, creased, loose, corroded, or fails after reseating, especially if known-good storage still behaves the same way.
When is this cable the right fix for sad iPod, clicking, or restore trouble?
Listen for repeated drive clicking and note whether the iPod reaches disk mode. Reseat the hard-drive ribbon and inspect the storage connector or retaining latch before buying another storage part. Try restore only after cable seating and power behavior are stable enough to complete the process. Compare with a known-good drive, cable, or flash adapter when available. Confirm thin or thick case thickness before ordering battery, hard drive, cable, or rear case parts. Listen for repeat clicking or repeated spin-up attempts before replacing storage parts. Check whether the iPod enters disk mode, restores cleanly, and is recognized by the computer. If a drive or flash adapter was just installed, recheck cable seating, adapter orientation, and formatting before buying another part. Choose this hard-drive cable only when clicking, sad iPod, restore, or disk-mode symptoms follow the storage path. Choose this cable only when clicking, restore failure, or disk errors follow this part or its connection path. Check battery stability, connector seating, and the hard-drive cable before treating the storage device alone as confirmed. Check the storage cable, adapter setup, battery power stability, and board connector when the symptom changes after reseating or swapping storage.
What should I check before replacing this cable?
Reseat the storage ribbon squarely and confirm the latch is closed before replacing the storage device again. Check adapter orientation, case clearance, and capacity/format expectations when using a flash path. Inspect the relevant ribbon and board connector before replacing the part. Look for lifted latches, bent contacts, debris, corrosion, creases, or torn flex material. Check whether the symptom changes after careful reseating. Choose this hard-drive cable only when the storage path remains isolated after ribbon and fitment details. Choose this cable only when the part's own flex or contact path is damaged. Check the cable and storage connector path first when the symptom started immediately after a storage swap. Check the board-side connector or adjacent cable first when the damage is not on the replaceable assembly.
Why people land on this part
Also searched as: 20GB HDD, gig drive, removed toshiba, toshiba 2004gal, drive logic, drive 60GB, hard drive dead, clicking sound, showing a folder, solid state drive, drive was corrupted, drive already corrupted, error 10, error 45, error 1429, click noise, click sound, malfunctioning with error, iTunes Error, iPod 4th generation stuck on apple logo, Won't Restore, Reboot Loop, iPod 4th Generation Monochrome Hard Drive IDE Ribbon Cable, iPod 4th generation connector, Sad iPod Icon, Folder Icon, Clicking Noise, Red X Icon, Corrupted Data, Hard Drive Failure.
You May Also Want
A fresh battery is often replaced during the same repair while the iPod is open.
Related: Flash Storage Mod Kit (iFlash IDE Adapter)Flash mod adapter connects via the same cable — verify cable integrity before modding.
Related: Replacement Hard Drive (20GB)If the cable is damaged, the hard drive may also need inspection or replacement.
Some buyers search for "Repair-guide facts worth keeping", "Missing larger-drive upgrade FAQ", or "Post-repair success expectation"; confirm the checks above point to this same part before ordering.
