Replacement rechargeable battery for iPod 4G Monochrome. Use it for poor runtime, swelling, or power loss after cable and power-source checks, while remembering that bad storage or board faults can imitate battery trouble.
Product Overview
This battery listing covers Replacement Battery (All Capacities) and its own connector path on the iPod 4th Generation (Monochrome).
Use Part Details for the confirmed part-number reference. Use the Compatible Variants table below to confirm capacity, color, case, or order-number fitment.
Choose this part when your iPod shows Won't Charge, Won't Turn On, Battery Drain, or Shuts Down Randomly; the checks below help confirm the right part before you order.
If a known-good battery, cable, and power source still do not restore stable power, the problem might be the dock connector, battery connector, or something on the board, not just the battery.
What Is Included
Condition: New replacement part. Quantity and exclusions: The listed part, set, pair, or configuration above is supplied with exactly one plastic pry tool. No other parts, tools, adhesives, or materials are included unless they are explicitly listed above.
Quick Buying Check
Buy this when
- Won't Charge: Verify the charger, cable, dock connector, and storage spin-up load first; use the battery check when runtime, no-charge, shutdown, or swelling behavior still follows the pack.
Diagnose first when
- Test with a direct USB connection to a computer before assuming the battery is dead. Some docks and wall chargers only supply FireWire power.
- Confirm thin or thick case thickness before ordering battery, hard drive, cable, or rear case parts.
- Confirm the capacity match before ordering: 20GB, 40GB.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1059 |
| EMC | EMC 1995 |
| Condition | New replacement battery |
| Capacity (Original) | 630 mAh |
| Capacity (Extended) | 630 mAh |
| Chemistry | Li-Ion |
| Voltage (Nominal) | 3.7V |
| Connector | Wired plug-in |
| Soldering Required | No |
| OEM Part |
616-0206, 616-0183
|
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| M9787LL/A | 20GB | Black/Red (U2) | thin | Yes | — |
| M9282LL/A | 20GB | White | thin | Yes | — |
| PE435A | 20GB | White (HP) | thin | Yes | — |
| M9268LL/A | 40GB | White | thick | Yes | — |
| PE436A | 40GB | White (HP) | thick | Yes | — |
Diagnostic Failure Cards
Use these model-specific failure cards to decide whether this battery is the right part, a nearby part needs checking first, or escalation makes more sense after simpler checks.
| Symptom | What it means & what to check |
|---|---|
| Symptom remains after basic checks |
What you may see: The iPod still points back to Replacement Battery (All Capacities) after cable seating, battery stability, and nearby connector checks. Check first: Retest with known-good cables or adjacent parts where practical before ordering. Check next: A nearby cable, connector, battery, storage device, display path, audio path, or board path can mimic a bad battery. |
| Symptom changes when touched or reseated |
What you may see: The symptom changes after moving the part, reseating a cable, or applying light pressure near the connector path. Check first: Inspect the connector, latch, flex, solder joints, and nearby board area for damage or corrosion. Check next: This can still be a connection issue rather than a failed battery alone. |
| Problem began after another repair |
What you may see: The issue started immediately after opening the iPod, replacing another part, or disturbing an internal cable. Check first: Reopen only as far as needed and inspect the exact area touched during the previous repair. Check next: Post-repair symptoms often trace to seating, latch, screw, or cable issues before Replacement Battery (All Capacities) itself is confirmed bad. |
| Dock, USB, sync, or charging connection trouble |
What you may notice
Diagnose first when
Similar issues to separate
When this battery fits
Where this battery does not fit Check another part first
Repair or replacement paths
|
| Ribbon, connector, or ground-path checks |
What you may notice
Diagnose first when
Similar issues to separate
Check another part first
|
| Fitment or model-variant mismatch |
What you may notice
Diagnose first when
Similar issues to separate
Check another part first
Repair or replacement paths
|
| Power, charging, or runtime symptoms |
What you may notice
Diagnose first when
Similar issues to separate
Check another part first
Repair or replacement paths
|
| Symptoms changed after repair or reassembly |
What you may notice
Diagnose first when
Similar issues to separate
Check another part first
Repair or replacement paths
|
| Fitment and inspection notes |
Repair considerations
Run these checks before replacing the battery — they confirm the battery is the right fix and not a nearby fault:
- Swollen or damaged batteries require safety framing
- Try known-good cable, charger, USB port, or computer
- Replace battery
Do Not Buy / Problems This Battery Does Not Fix
| Situation | Start here instead |
|---|---|
| Variant or capacity does not match this listing | This is a different model — check your order number and generation before ordering. |
| You see a folder icon, clicking noise, or restore failure | Check the drive or flash media, storage cable, adapter seating, formatting, and restore path before replacing any part. |
| Only the screen is affected and everything else works | Start with the screen, display ribbon, backlight path, and battery-swelling inspection. |
| Charging, swelling, runtime, or power is the primary problem | Check the charger, cable, port condition, and battery connector before replacing the battery. |
| Recent service or connector disturbance is the main clue | Inspect the disturbed connector, latch, ribbon, flex path, and corrosion signs before ordering another battery. |
| A symptom points to a different part | iPod Photo / 4th Gen Color uses the same battery family (616-0206/616-0183). |
Install Overview
Before You Start
Turn Hold off, use the reset sequence for this generation, and confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Reseat nearby ribbons and connectors before blaming a replacement battery.
Stop charging and avoid puncturing, bending, or compressing the cell if the battery is swollen, hot, leaking, or visibly damaged.
Disassembly Guide
Disassembly guide summary: iPod 4th Generation or Photo Battery Replacement.
Show all 8 installation steps
Before you open the iPod, confirm that the hold switch is in the locked setting. The orange bar should be showing, indicating hold is active.
Move an opening pick as far as possible into the gap between the plastic front and the metal back panel, on the right edge of the iPod. You may have to rock the pick back and forth to move it in farther. With the opening pick, lever up against the plastic front panel and release 5 retaining tabs. Slide the pick along the iPod edge and keep levering gently until the remaining retaining tabs release. In this step, after all five tabs along the right edge are free, the case should easily open.
The iPod case is now open, but do not separate the two halves yet. An orange ribbon cable still connects the headphone jack to the logic board. With the dock connector edge at the top, open the case like a book and set the rear panel beside the iPod front half.
With a plastic tool or your fingernails, carefully detach the orange headphone jack cable. Make sure to draw straight up on the connector, not the cable itself. This fragile ribbon cable can stay connected for a battery replacement. Prop and tape the rear case against a box so the headphone jack remains connected to the motherboard without straining its cable while you work.
Carefully detach the white battery connector from the logic board. Pull only on the connector housing, not the cables.
Take out the 2 black T6 Torx screws from the left edge of the logic board.
Use one hand to raise the hard drive up in order to access the battery beneath. Carefully thread the battery cable around the logic board end. While freeing the cable, avoid pulling upward too far on the logic board.
Raise the battery out of the front housing by pulling it up by the battery leads. If necessary, grip the battery and pull it off the adhesive securing it to the front case. It may be helpful to with a spudger, lever the battery up off its adhesive. Raise the battery up and out of the front case.
Product-specific placement, reassembly, and check
- Prepare and access. Confirm the exact model and listing fit first. Use the existing steps as a disassembly guide, gather the specified tools, disconnect power where applicable, and keep screws and cable positions organized.
- Place Replacement Battery (All Capacities). Seat the battery in the original battery location, route its lead or ribbon without a pinch, and reconnect it squarely.
- Reassemble without force. Reverse only the access steps needed for this repair, keep cables clear of case edges and screw posts, and close clips in stages.
- Validate before final closure. Before final closure, confirm boot and charging behavior and stop immediately for swelling, heat, odor, hissing, smoke, or leakage.
Stop condition: Stop if a connector, latch, screw, clip, housing edge, or the replacement part resists normal alignment. Recheck model fit, orientation, cable routing, and trapped hardware instead of forcing it.
After This Repair
| Check | What to do |
|---|---|
| Charge and calibrate | Charge fully, let it stay on the charger a little longer, then use it through a normal discharge and charge cycle so the meter can settle. |
| Watch the internal stack | If the display shows pressure marks, dark spots, or case bowing after reassembly, reopen and check battery thickness and cable routing. |
| Still not working? | Check the dock connector, battery connector, storage load, and board power path before replacing another battery. |
Battery Safety & Shipping
⚠️ Lithium-Ion / Li-Po Battery Safety. This product contains (or is) a rechargeable lithium-ion/lithium-polymer battery. Charge only with a compatible charger and unplug once fully charged. Avoid charging or storing in direct sunlight or other high-heat environments. Stop using and stop charging immediately if the battery swells, bulges, gets unusually hot, hisses, smokes, or leaks. Do not puncture, crush, bend, short-circuit, or try to "deflate" a swollen cell, and never press a lifted screen or case back down — it can rupture the cell. If electrolyte contacts your eyes, flush with clean water for 15 minutes without rubbing and seek medical care; on skin, wash with water and soap. Battery service should be done by a trained technician. Recycle through an electronics or universal-waste recycler, not household trash.
Shipping. A refurbished iPod shipped with its battery installed is handled as lithium-ion batteries contained in equipment (UN3481); a loose replacement cell is handled as a lithium-ion battery (UN3480). Carrier, packaging, and destination restrictions can vary, so follow the current checkout and shipping instructions for the offered route.
Worth Knowing
- Same 630 mAh battery fits both thin (20GB) and thick (40GB) case variants.
- Battery sits BEHIND the click wheel — a swollen battery can press on the click wheel causing phantom input or complete input failure. This layout is unique to the 4G/Photo platform.
- First fullsize iPod with USB charging — battery charges via both FireWire and USB.
Stuck On Apple Logo: What Owners Describe
On the iPod 4th Generation (monochrome), Stuck On Apple Logo can describe more than one observable problem. These paraphrased owner reports are anecdotal starting points for diagnosis, not proof that any single part failed.
Anecdotal owner reports (not a guarantee or authoritative proof): - Another owner reported that the iPod remained at the Apple logo after a battery replacement and would not enter disk mode.
Owners searching for this describe it as: iPod 4th Generation (monochrome) Stuck On Apple Logo, iPod stuck on Apple logo, iPod Apple logo freeze.
What Owners Report
These are anecdotal owner reports, not guarantees or authoritative proof that a particular part will fix a symptom. Use them as a troubleshooting starting point: confirm the symptom, run the quick checks, then match the fix.
Will not charge, or shows an odd charging icon
Symptoms. Battery icon with a zig-zag shape through it while the computer sees nothing; an electrical-outlet-and-charger picture locked on screen; the charge graphic blinks or loops but the battery never fills; dead after a whole night plugged in; works while plugged in but dies the moment it's unplugged; a used unit that never reaches full charge.
Quick diagnosis.
- Read the icon first — two different icons get mistaken for a charging fault. The wall-outlet-with-charger picture after a restore or update means the firmware finished its computer stage and is waiting on external power to complete installation. That is normal behavior, not a fault and not a brick — see the FireWire note under Fixes.
- A monochrome, non-animated battery icon while on a USB port means the pack is too far discharged for the device to communicate with the computer at all. Charge first — a FireWire wall adapter is the community's go-to for this state — and only then judge other components.
- Battery-first triage on used or unknown-history units: fit a known-good battery before chasing dock, drive, or board faults. "Works plugged in, dies unplugged" is the classic worn-pack signature.
- Dock-side electrical check: inspect the dock connector inside and out for debris and bent or corroded pins. With the unit plugged in, battery-connector voltage should read about 4.2–4.6V (one owner's multimeter procedure).
- Reset ladder before hardware conclusions: Menu + Select for about 10 seconds until the logo appears, then retry on a high-power USB 2.0 port (not an unpowered hub), then an iTunes restore.
Fixes.
- Battery replacement (616-0206 class) — one pack serves both the thin 20GB and the thick 40GB builds. The community sourcing tip is to search by the 616-0206 number itself.
- 12V FireWire power for restore completion and deep-discharge wake — this model charges over USB in normal use, but a deeply discharged pack and a stalled restore both respond to a 12V FireWire source; Apple's own service flow charges over FireWire before battery testing. Owners who service several of these keep an inexpensive FireWire wall adapter on hand for exactly these two cases.
Cautions.
- Shipping restrictions apply to battery orders in some regions; plan sourcing accordingly.
- One thread in this family is from a color-screen-sibling owner; its charging anecdotes are shared-family habit, not evidence about this model.
- Off-model reset advice (a touch-screen-style slider procedure) circulates in these threads — the reset on this model is Menu + Select, nothing else.
Community signal. Reported by 13 owners — the model's most-reported issue.
Won't charge fully, or a new battery is still not recognized
Symptoms. New pack fitted but the same low-battery signs persist; the unit charges but the computer and iTunes stay blind to it; the charge logo sits at the same level after a whole night; shows charged, then dies unplugged; won't hold charge after a swap and a calibration attempt.
Quick diagnosis.
- Dock-connector inspection first: look inside and out for fluid marks, lint, dust, corrosion, and bent pins; clean with >90% isopropyl alcohol and a soft brush before replacing any part.
- If a new battery charges but the computer stays blind: the pack may still be too low for the device to announce itself. Give it real time on a FireWire wall adapter first, then retry USB.
- Charge logo stuck after a repair: re-check the 632-0259-A drive ribbon's seating — a mis-seated ribbon mimics charge and boot faults.
From long-term use. An owner-operator who services this model summarizes its power behavior this way: it syncs over USB and charges on either USB or FireWire, but the port must actually supply charging current — many laptop ports don't — and a restore finishes only after the external-power handshake (see the restore entry).
Fixes.
- Quality pack from a reputable source — some "new" packs are old cells behind a fresh gauge board showing zero cycles; they never charge properly. Exchange defective packs rather than troubleshooting around them.
- FireWire wall adapter as bench equipment — it resolves the restore-completion and deep-discharge cases that ordinary USB ports often can't.
Cautions.
- Poor-quality aftermarket batteries are prevalent; a defective-out-of-box replacement is a live possibility when symptoms persist after a swap.
- Battery-health readout apps exist for computers; treat their numbers as a hint, not a verdict.
Community signal. Reported by 7 owners.
Problems after a battery replacement
Symptoms. Unresponsive after the swap with either the old or the new pack; won't turn on; cycling Apple logo, then sad face, then low-battery symbol; a replacement pack that lasts under an hour.
Quick diagnosis.
- Re-verify every connection you disturbed: battery plug fully seated in its receptacle, receptacle not lifted from the board (inspect the small solder joints), and the drive path intact. Mis-seats mimic dead devices.
- Give the new pack a LONG first charge on a wall or FireWire adapter — owners report roughly two hours of FireWire pre-charge before doing anything else, and one saw over a day on a wall adapter before a new pack settled. Judge the repair after the charge, not.
- Split test with the computer: if iTunes sees the device but the screen stays dark, look at the display; if iTunes sees nothing, suspect the just-replaced battery first, then the drive and its cable.
- Cycling logo/sad-face/low-battery: reset (Menu + Select about 10 seconds), then force disk mode and restore from there. Two button combinations circulate for disk mode on this model — Fast-Forward + Rewind, and Play + Select — try both.
Fixes.
- Match the replacement's spec — verify size and current rating before install, then run an iTunes restore to clear charge-logic confusion.
- Exchange defective replacements — packs arrive dead often enough that one owner went through two vendor exchanges without reviving the unit; if a second pack changes nothing, shift suspicion to the drive.
Cautions.
- Battery access requires lifting the hard drive: the 632-0259-A ribbon unseats easily, and a blinking folder icon after reassembly usually means the data path, not a dead drive.
- The battery plug is a straight-up friction pull — no lever, no latch. Prying sideways damages the receptacle and its solder joints.
Community signal. Reported by 5 owners.
Frequently Asked Questions
Use these questions to narrow the part path before ordering. They keep each answer focused on a different diagnostic or fitment decision.
What iPod 4th Generation (Monochrome) models does this fit?
This Replacement Battery (All Capacities) fits: M9282LL/A (20GB White), M9268LL/A (40GB White), M9787LL/A (20GB Black/Red (U2)), PE435A (20GB White (HP)), PE436A (40GB White (HP)).
Do I need to solder?
No, this installation does not require soldering.
How do I know if this battery needs replacement?
Symptoms that can point to this battery include: Won't Charge, Won't Turn On, Battery Drain, Shuts Down Randomly, Swollen Battery. Check fitment, connectors, and nearby parts before treating symptoms as proof.
Can storage trouble look like a bad battery?
Listen for repeated drive clicking and compare whether the symptom changes in disk mode or during restore. Reseat the hard-drive ribbon before replacing the battery again when power symptoms began after service. Confirm thin or thick case thickness before ordering battery, hard drive, cable, or rear case parts. Listen for repeat clicking or repeated spin-up attempts before replacing storage parts. Check whether the iPod enters disk mode, restores cleanly, and is recognized by the computer. If a drive or flash adapter was just installed, recheck cable seating, adapter orientation, and formatting before buying another part. This battery may still help when runtime is poor after storage symptoms are ruled out. Choose this battery only when clicking, restore failure, or disk errors follow this part or its connection path. Check the storage path first when sad iPod, clicking, or restore failure is the main event. Check the storage cable, adapter setup, battery power stability, and board connector when the symptom changes after reseating or swapping storage.
What should I check before replacing this battery?
Inspect the battery connector and nearby ribbon paths before ordering another battery. Look for corrosion, torn flex material, or a connector that no longer clamps the battery lead cleanly. This battery helps only when the battery itself remains the isolated failure after seating checks. Check disturbed connectors first when the symptom appeared immediately after service.
Is this an iPod Classic?
Apple's 'Classic' branding started with the 6th Generation (2007). This is the iPod 4th Generation (Click Wheel), the monochrome-screen model from 2004. Apple's official name for this model is iPod (Click Wheel).
