Replacement internal cable for iPod Video 5G. Use it when the flex or ribbon is torn, creased, loose, or failing at the connector before blaming the whole attached assembly.
Product Overview
This cable listing covers Hard Drive ZIF Ribbon Cable (Hitachi) and its own connector path on the iPod 5th Generation (Video).
Use Part Details for the confirmed part-number reference. Use the Compatible Variants table below to confirm capacity, color, case, or order-number fitment.
Choose this part when your iPod shows Sad iPod Icon, Clicking Noise, Red X Icon, or Folder Icon; the checks below help confirm the right part before you order.
- Note that the hard drive will need permanent replacement eventually, as this temporary fix only addresses a stuck mechanism.
- Clicking indicates drive failure; confirm with a ZIF-to-USB adapter
- Back up all data before attempting an iTunes restore
- This erases all data and reinstalls factory firmware
- The clicking indicates a mechanical hard drive failure, while the blank screen may resolve after a successful hard reset.
- Back up all data before formatting or restoring
- Error 1429 during an iTunes restore has several potential fixes.
- To resolve error 1416 when restoring, try the following methods: Method 1 - Disk Mode with timed cable connection: 1.
- If the hard reset fails, restore through iTunes (this erases all iPod data)
- Error 1429 during restore has multiple documented solutions
- The sad face icon with a web address and audible drive noise indicates a failing hard drive.
- To resolve Error 1437 during restore, try completely reinstalling iTunes: 1.
- Intermittent restore screen often indicates firmware loss from a failing hard drive
- Reformatting the drive will erase all data
- No standalone firmware upgrade exists for the A1136 80GB
- iTunes restore in Disk Mode erases all content but reinstalls fresh firmware
- Clicking sounds indicate the hard drive is not functioning properly
- A firm tap can sometimes temporarily free a stuck drive head
- Error 1437 can be resolved by completely uninstalling and reinstalling iTunes
- Important: "Update" only installs new software without erasing data. "Restore" erases all content and returns the iPod to factory condition.
- Sad face icon with drive noise indicates hard drive failure
- Update preserves data; Restore erases everything and returns to factory condition
- To resolve error 1416 after a hard drive replacement, follow this escalating diagnostic sequence: 1.
- Error code 1415 during iTunes restore has documented solutions from Apple
- For iFlash conversions: reformat SD card to FAT32 with all partitions deleted
- Even with a bad HDD, the iPod should show some sign of life (Apple logo)
- The hard drive is the only iPod component that produces audible noise
- Enter Diagnostic Test Mode: hold Menu + Select, release at Apple logo, then immediately hold Back (|<<) + Select until drive spins up
- Error 1416 can be resolved by formatting the drive before attempting restore
Choose Your Option
This part comes in multiple variants. Confirm your iPod's capacity, case depth, and order number before ordering.
Fitment is based on the hard-drive brand inside the iPod, not only the rear-case capacity. Open the iPod or verify the installed drive model before choosing the Hitachi cable.
You're viewing this optionUse this linked storage option only for 30GB / 80GB iPods and the order numbers shown here.
View this option →What Is Included
Quick Buying Check
Buy this when
- Storage errors with a known-good drive: A damaged or loose ZIF cable can make a good drive look failed.
- Intermittent detection after repair: Cable seating and latch damage are common after opening the iPod.
Diagnose first when
- 5G Video has Toshiba, Hitachi, and 5.5G ZIF cable variants. Match the cable to the original drive and case revision before ordering.
- Check for torn flex traces, creases, or damaged ZIF contacts.
What Brings People Here
Flash-mod preparation
Match the rear engraving or case choice to an upgraded storage build after confirming the storage path.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1136 |
| EMC | EMC 2065 |
| Condition | Used — factory original Apple part. Normal cosmetic wear expected. |
| OEM Part |
821-0387-03, 632-0340
|
| Interface | ZIF-40 storage ribbon |
| Variant Notes | Hitachi-drive cable, all A1136 capacities; Hitachi-drive cable alternate supplier identifier, all A1136 capacities |
| Cable Variant | Hitachi hard-drive cable |
| Compatible Drive Brand | Hitachi |
| Compatible Drive Models | HTC306030G5CE00, HTC426060G9AT00 |
| Fitment Rule | Match cable to installed drive brand |
| Model Family | iPod Video A1136 5G / 5.5G Enhanced |
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| MA146LL/A | 30GB | Black | thin (0.43 in) | Yes | — |
| MA002LL/A | 30GB | White | thin (0.43 in) | Yes | — |
| MA147LL/A | 60GB | Black | thick | Yes | — |
| MA003LL/A | 60GB | White | thick | Yes | — |
| MA452LL/A | 30GB | U2 Special | thin (0.43 in) | Check fitment | Compatibility was not present in legacy fitment data; verify before publishing. This variant has not been verified yet. |
| MA664LL/A | 30GB | U2 Special | thin (0.43 in) | Check fitment | Compatibility was not present in legacy fitment data; verify before publishing. This variant has not been verified yet. |
| MA446LL/A | 30GB | Black | thin (0.43 in) | No— wrong drive manufacturer | Hard-drive cable must match installed drive manufacturer; this row is Toshiba, not Hitachi Use Hard Drive ZIF Ribbon Cable (Toshiba) instead. |
| MA444LL/A | 30GB | White | thin (0.43 in) | No— wrong drive manufacturer | Hard-drive cable must match installed drive manufacturer; this row is Toshiba, not Hitachi Use Hard Drive ZIF Ribbon Cable (Toshiba) instead. |
| MA450LL/A | 80GB | Black | thick | No— wrong drive manufacturer | Hard-drive cable must match installed drive manufacturer; this row is Toshiba, not Hitachi Use Hard Drive ZIF Ribbon Cable (Toshiba) instead. |
| MA448LL/A | 80GB | White | thick | No— wrong drive manufacturer | Hard-drive cable must match installed drive manufacturer; this row is Toshiba, not Hitachi Use Hard Drive ZIF Ribbon Cable (Toshiba) instead. |
Failure Signs
Use these checks to decide whether this cable is the right part, whether a nearby part should be checked first, or whether the symptom needs more diagnosis.
Restore, sync, setup, or frozen-state symptoms
What you may see: People describe restore loops, sync trouble, frozen screens, language/setup screens, or diagnostic states that make a part look suspect.
Check first: Separate a one-time software or restore state from a repeatable hardware symptom.
- Check whether the symptom changes in disk mode, diagnostic mode, or after a supported reset.
- If the state appeared after part replacement, inspect the related ribbon and connector before buying again.
- Reseat both ends of the storage ribbon and inspect the connector or latch before replacing the cable.
Most likely cause: Choose this cable only when the same hardware symptom repeats outside the temporary device state.
- Replace the cable when the symptom follows that part across normal use and restore/setup states.
- Continue software, storage, power, or input diagnosis when the symptom appears only during setup or restore.
Look elsewhere when: Check storage, battery power, input state, and connector seating first when the symptom is tied to restore or setup.
Sad iPod, clicking, restore, or storage trouble
What you may see: People describe clicking, sad iPod or folder screens, restore loops, disk-mode trouble, or storage that will not behave after replacement.
- Sad iPod, red X, clicking drive, restore loop, or disk-mode trouble.
Check first: Listen for repeat clicking or repeated spin-up attempts before replacing storage parts.
- Check whether the iPod enters disk mode, restores cleanly, and is recognized by the computer.
- If a drive or flash adapter was just installed, recheck cable seating, adapter orientation, and formatting before buying another part.
Most likely cause: The cable can be involved, but the drive cable, adapter formatting, power stability, or logic-board storage path may also be responsible.
- Check storage / restore route, connector seating, and board-side damage before ordering.
- Choose this cable only when clicking, restore failure, or disk errors follow this part or its connection path.
- Choose this cable when the symptom remains isolated to this assembly, its ribbon, or its connector path after first checks.
- Replace the cable only when the storage or restore symptom is tied to this part's role in the startup path.
- Use cable, adapter, or board diagnosis first when restore behavior changes with seating, formatting, or another known-good storage device.
Look elsewhere when: Check the storage cable, adapter setup, battery power stability, and board connector when the symptom changes after reseating or swapping storage.
Cable ribbon, connector, or contact path
What you may see: People describe symptoms that change after opening the iPod, reseating parts, or disturbing nearby flex cables.
- A symptom starts after opening the iPod or disturbing an internal flex cable.
Check first: Inspect the relevant ribbon and board connector before replacing the part.
- Look for lifted latches, bent contacts, debris, corrosion, creases, or torn flex material.
- Check whether the symptom changes after careful reseating.
Most likely cause: The cable may be fine while its ribbon, connector, latch, or contact path is loose, dirty, damaged, or not fully seated.
- Connector seating, ribbon damage, or ground-path issues can involve this part, a nearby connector, or a board path.
- Choose this cable only when the part's own flex or contact path is damaged.
- Reseat or clean only where the repair procedure supports it.
- Replace the cable when the flex, connector tail, or assembly contact path is physically damaged.
Look elsewhere when: Check the board-side connector or adjacent cable first when the damage is not on the replaceable assembly.
Fitment or model-variant mismatch
What you may see: People ask whether a similar-looking part from another capacity, case thickness, or generation will work.
Check first: Match the exact model, generation, capacity, and case style shown for the product.
- Do not use a symptom to override fitment: a wrong-variant part can create new symptoms after installation.
Most likely cause: This cable may help only when it matches the model and variant being repaired.
- Use the cable variant matched to the exact iPod.
- Recheck fitment before diagnosing a newly installed part as defective.
Look elsewhere when: Check fitment before replacing nearby parts or ordering another copy of the same wrong variant.
Symptoms changed after repair or reassembly
What you may see: People describe a new problem appearing immediately after battery, storage, display, audio, or control work.
- A new symptom appeared after battery, storage, audio, display, or control work.
Check first: Reopen only as far as needed to inspect the areas touched during the repair.
- Compare the new symptom with what worked before the repair.
- Check cable seating, latch position, and part variant before replacing a second part.
Most likely cause: A post-repair symptom can involve the cable, but disturbed ribbons, latches, grounding, connector seating, or the wrong variant part are common checks before ordering again.
- Check post-repair regression, connector seating, and board-side damage before ordering.
- Choose this cable only when the part itself was torn, creased, or damaged during service.
- Correct seating, latch, or variant problems first.
- Replace the cable when the repair damaged that assembly or its flex path.
Look elsewhere when: Check the exact connector or assembly disturbed during the repair before treating the new part as failed.
Cable symptoms to compare before ordering
What you may see: People describe behavior that can point toward the cable, but the symptom does not prove this part has failed
Check first: Compare the exact behavior, when it started, and whether it changed after a repair
- Inspect nearby cables and connectors before replacing major parts
Other Symptoms That May Involve This Part
| Commonly described as | What to check before ordering |
|---|---|
| shows a folder, showing a folder | Reseat both ZIF ends and inspect the fold line; the cable is stronger evidence when the icon appears immediately after the Apple logo. |
| drive dead, hard drive dead | Drive-health language is not proof of a bad cable. Inspect the cable ends, fold line, and ZIF locks while also checking the drive or adapter itself. |
| restore error | Check cable seating, ZIF locks, storage format, and USB behavior before treating the cable as failed. |
| apple logo | Apple-logo hangs can come from storage not initializing; check the cable and storage device together before buying either part. |
| clicking sound | A drive can make the same sound, so reseat the cable and compare against known-good storage before buying the ribbon. |
| hdd sound | Treat this as a storage-path clue, then compare cable condition, drive behavior, and fitment. |
| error 1416, error 1429, error 1439 | Restore and iTunes errors can involve the storage path; reseat the cable, confirm adapter or drive format, and test known-good storage before replacing the ribbon. |
Repair considerations
Repair specialists who work on this model consistently flag these checks before replacing the cable — they help confirm the cable is the right fix and not a nearby fault:
- Restore/format steps can erase data or indicate storage failure
- Treat ribbons, tabs, and ZIF connectors as fragile
- Use reset, Disk Mode, restore, or iTunes/Finder behavior as a software/storage check
- Inspect ZIF latch, socket, or clamp condition
- Reseat or inspect ribbon cable and connector seating
- Check drive noise, SMART/data signs, or storage recognition
Do Not Buy This Cable Yet If...
| Situation | Start here instead |
|---|---|
| You see a folder icon, clicking noise, or restore failure | Start with the storage drive, drive cable, or flash-storage check for your model before buying this part. |
| Variant or capacity does not match this listing | Use the Hard Drive ZIF Ribbon Cable (Toshiba) listing instead. |
| The problem is the Hold switch or headphone jack, not this part | Use the port, cable, host, or power path if the storage ribbon is not the isolated fault. |
| Cable, computer, sync, or port behavior is the primary problem | Check the matching drive, cable seating, and board-side connector before ordering. |
| Only the screen is affected and everything else works | Check the display path and ribbon seating before replacing this part. |
| Recent service or connector disturbance is the main clue | Inspect and reseat the cable, latch, or connector path disturbed during service before buying another part. |
- The iPod 5th Generation drive is interchangeable, but the 30GB model uses a slim drive.
- There is no separate firmware upgrade available for the iPod 5th Generation (Video) A1136 80GB.
- Model A1136 is the iPod 5th Generation (Video)
Install Overview
Before You Start
Turn Hold off, use the reset sequence for this generation, and confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Reseat nearby ribbons and connectors before blaming a replacement cable.
If the display shows pressure marks, dark spots, bowing, or lifting after repair or battery replacement, stop reassembly and inspect internal fit before treating the display alone as failed.
If the symptom appeared after opening the iPod or replacing a part, inspect and reseat nearby ribbon cables and connectors before assuming the replacement part is bad.
Verify the exact generation, capacity/thickness variant, connector, and part listing before ordering; similar-looking iPod parts are not always interchangeable.
Open ribbon-cable latches only as described; over-lifting or side-loading the latch can damage the connector. Do not fully separate the case halves until the remaining ribbons are released; the back panel can still be connected by ribbon cables. Check drive-ribbon seating and bumper placement while the iPod is open.
Repair Guide
Repair guide summary: iPod 5th Generation (Video) Hard Drive Cable Replacement.
Show all 12 installation steps
Before opening the iPod, confirm that the hold switch is locked. With the iPod screen-side down and facing you, the slider should sit all the way to the right.
Do not get discouraged if the iPod takes several opening attempts; work slowly until the case releases. Release the first bottom retainer clip with the plastic opening tool. Point the tool edge toward the metal rear case to avoid scratching the plastic front.
Use these retaining clip locations: four along each side, one on top, and two along the bottom. This helps avoid frustration and reduces the chance of scratching the plastic cover.
Each side of the iPod has four retaining clips. Use a plastic opening tool to separate the plastic front from the metal rear case. Slide the plastic opening tool into the iPod's left side with the tool edge pointed toward the metal rear case. A small guitar pick can help with opening. Place it in the seam and slide it around the case to release the clips more smoothly. Gently enlarge the existing crevice by wiggling the plastic opening tool and moving it to the left. Keep working this way until the entire side of the iPod is loose. Then slide a plastic opening tool to the right of the Hold button. Work very carefully while inserting the tool because the display is fragile.
Gently glide the plastic opening tool on the top of the display, making sure to release the retaining clips. The other sides of the iPod should now release easily. If they do not, work plastic opening tools along the right side the same way you did on the left side. In this step, separate the front of the device from the back about an inch (or a couple of centimeters). The iPod casing is now open, but do not fully separate the two halves yet. Two ribbon cables still connect the back panel to the remaining iPod assembly.
With angled tweezers or a plastic opening tool, slide the brown connector latch upward where it secures the orange battery ribbon cable. Pull from both sides of the latch. Lift it only about 1-2 mm to release the cable; do not lift farther or remove it, or the white connector may come with it. Do not raise the assembly very far; lifting too high could pull the battery connector out of the logic board. Move the brown connector straight upward. It is fragile and can break if shifted to the side. Hooks at the bottom hold the cable in place. If an arm breaks, reinstalling the battery cable becomes difficult; put the cable in the slot and press the brown holder into place to stop the cable from slipping out. Take the cable out of the connector.
At this stage there should be one orange ribbon cable still attaching the front housing to the back. At this stage you are able to take out and replace the blue rubber bumpers, or keep going with separating the case. You can replace the battery without separating the case, but opening it farther can make the work easier. Doing so requires one extra cable removal and adds some damage risk.
Raise the hard drive so the headphone jack ribbon connector is exposed. If the hard drive bumpers come loose, put them back with the notch seated in its original orientation.
With the plastic opening tool, gently raise the brown tab of the headphone ribbon cable connector. The tab can rotate up 90 degrees, releasing the ribbon cable. With your fingers, draw out the headphone jack ribbon cable.
The front and rear case halves should now be fully separated.
With a small plastic opening tool, release the black hinge clamping the hard drive ribbon cable. Rotate the tab upward 90 degrees toward the logic board to free the ribbon cable. With your forefinger, hold the ribbon cable in place; detach the drive from the ribbon cable. Confirm that the hard drive rubber side bumpers are installed on the drive. Use the side bumper installation guide for placement. If needed, transfer the blue foam padding from the hard drive to the replacement drive.
With the small plastic opening tool, release the brown clamp securing the hard drive cable. The tab rotates upward 90 degrees toward the display and frees the ribbon cable. Move the orange hard drive ribbon cable straight out of its connector. If adhesive holds the cable to the logic board, carefully pull up on the cable to loosen it.
After This Repair
| Check | What to do |
|---|---|
| Test the connected part | Confirm the assembly on both ends of the cable behaves normally before closing the iPod. |
| Still not working? | Inspect the latch, cable orientation, and board-side connector before replacing another part. |
Frequently Asked Questions
Use these questions to narrow the part path before ordering. They keep each answer focused on a different diagnostic or fitment decision.
Does click of death mean the drive is dead?
Not by itself. Repeating clicks, Sad iPod, Red X, or Folder Icon can involve the drive, this cable, adapter setup, or board storage path. Reseat the cable at both ends and confirm the installed drive brand before buying a replacement cable.
Is this the 30-pin dock connector?
No. This is the internal hard-drive ribbon cable. The 30-pin dock connector, battery connector, LCD connector, and sync-port path are different repairs.
Is this for an A1238 iPod Classic?
No. This listing is for iPod Video A1136 5G / 5.5G Enhanced models. A1238 is the later iPod Classic family and uses a different storage-cable layout.
What should I check before buying this cable for board failure vs peripheral checks?
Use logic-board replacement as a last check, not a first guess. Battery ZIF seating, HDD cable detection, display ribbon, ground strap, click-wheel ribbon, headphone/hold ribbon, dock pins, and charge-current evidence can all mimic board failure. A board diagnosis is stronger after those parts are seated, matched, and tested.
For very-low-battery, charging, or no-power symptoms, what checks come before replacing parts?
Use the correct thin- or thick-case battery, then inspect the fragile ZIF battery ribbon and latch. A charge icon or reported full charge does not checks before ordering the battery, thermistor, charge path, storage cable, or drive. Check battery readings, charge current, USB power, Disk Mode, and storage behavior separately before deciding the fault is one part.
What should I check before buying this cable for lines and pixel?
Vertical lines, horizontal lines, dead pixels, yellowing, clouding, and dark pressure marks are not all the same failure. Reseat the LCD ribbon first, then separate panel damage, polarizer aging, swollen-battery pressure, and wrong-display fitment before ordering parts.
What should I check before buying this cable for display and front panel reassembly?
Display reassembly: Seat the screen between the front panel and framework before reconnecting the display ribbon. A stiff replacement cable can lift the screen back out of position if alignment is not checked before closing.
Can power symptoms make storage diagnosis misleading?
Confirm the battery can hold the iPod on before judging a drive or flash adapter. Watch whether shutdown happens exactly when storage is accessed. Choose this hard-drive cable only when power is stable but storage access still fails. Check battery and charger behavior first when the iPod cannot stay powered long enough to test storage.
Why people land on this part
Use the checks above to separate this cable from nearby parts before ordering.
Some buyers search for "HDD ribbon", "iPod video 5th generation hitachi hard drive cable", "drive flex cable", "iPod classic hard drive cable", "A1136 hard drive cable", "corroded", "broken connector", "storage failure diagnosis", "cable seating after drive or flash mod service", or "short runtime, charging trouble, sudden shutoff, or a device that will not reliably power on"; confirm the checks above point to this same part before ordering.
Also searched as: iPod 5th Generation Video Hard Drive ZIF Ribbon Cable, iTunes Error, Corrupted Data, Reboot Loop, Stuck in Recovery Mode, Stuck on Apple Logo, Flash Mod Problems, Hard Drive Failure, 30GB HDD, 80GB hard drive cable, plastic piece, drive upgrade, solid state drive, sound like HDD, click noise, click sound, ipod video 5th generation hitachi hard drive cable, Sad iPod Icon, Clicking Noise, Red X Icon, Folder Icon, hard drive dead, clicking sound, shows a folder, restore error, broken connector, A1136 hard drive cable, drive flex cable, error 1416, error 1429.
Worth Knowing
- 821-0387-03: Hitachi-drive cable, all A1136 capacities
- 632-0340: Hitachi-drive cable alternate supplier identifier, all A1136 capacities
- Cable brand must match drive brand; Toshiba-drive and Hitachi-drive cable paths are used across A1136 capacities.
- Sad iPod icon with Apple support URL indicates hard drive failure
- The "www.apple.com/support/ipod" message indicates a failing hard drive, which is the most common cause of this error.
- Error 1429 is most commonly caused by a bad hard drive or improperly connected storage
- Error 1416 is commonly caused by drive communication issues
You May Also Want
A fresh battery is often replaced during the same repair while the iPod is open.
Related: Flash Storage Mod (iFlash Adapter + SD Card)Use flash-mod guidance when converting the storage path to an iFlash or SD-card setup.
Related: Hard Drive ZIF Ribbon Cable (Toshiba)Use the Toshiba cable if the installed drive label is Toshiba.
