Replacement housing or trim part for iPod Mini 2nd Generation. Use it to restore fit, finish, color, case alignment, or visible damage rather than to fix an internal electronics fault.
Product Overview
Choose this housing listing to restore the visible fit, finish, or mounting hardware on the iPod Mini 2nd Generation.
Use the Compatible Variants table below to confirm capacity, color, or order-number fitment.
This is a fit-and-finish part, so choose it by physical damage, color, part shape, and missing hardware rather than by an electrical symptom.
What Is Included
Condition: Used factory-original part. Quantity and exclusions: The listed part, set, pair, or configuration above is supplied with exactly one plastic pry tool. No other parts, tools, adhesives, or materials are included unless they are explicitly listed above.
In the box: one bottom bezel and one plastic pry tool. Not in the box: the metal retaining bracket that sits beneath this bezel, the dock connector itself, the aluminum tube, the top bezel, and any adhesive — each of those is a separate part.
Quick Buying Check
Buy this when
- Use this listing when the original plastic dock port bezel is damaged, missing, mismatched, or physically worn; diagnose internal symptoms separately.
- The original part is cracked, scratched, dented, bent, missing, loose, or cosmetically worn.
- The model, color, model-specific fitment, and capacity family match this listing.
Do not buy for
- Do not use this part for: a dock port that will not charge or sync, or bent and corroded pins — on this model the 30-pin connector is part of the logic board and this white bezel only frames its opening.
- Do not use this part for: the aluminum tube, the top headphone bezel, the click wheel, logic board, battery, or storage drive.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1051 |
| EMC | EMC 2044 |
| Condition | Used — factory original Apple part. Normal cosmetic wear expected. |
| Material | Plastic |
| Color | White |
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| M9802LL/A | 4GB | Blue | — | Yes | — |
| M9806LL/A | 4GB | Green | — | Yes | — |
| M9804LL/A | 4GB | Pink | — | Yes | — |
| M9800LL/A | 4GB | Silver | — | Yes | — |
| M9803LL/A | 6GB | Blue | — | Yes | — |
| M9807LL/A | 6GB | Green | — | Yes | — |
| M9805LL/A | 6GB | Pink | — | Yes | — |
| M9801LL/A | 6GB | Silver | — | Yes | — |
Cosmetic Failure Signs — When to Replace
This housing is a cosmetic part — it does not change how the iPod plays, charges, or syncs. Replace it when the damage is physical:
| Symptom | What it means & what to check |
|---|---|
| Cracked or split white plastic | The trim splits at the corners and along the pry line — usually from an earlier opening, or from a drop onto the dock end of the iPod. |
| Chewed edges and pry marks | Levering the bezel out marks the soft plastic; once the lip is deformed the trim no longer sits down flush against the aluminum tube. |
| Yellowed, dull, or stained white | Age, sunlight and handling take the white off; next to a clean tube and a fresh click wheel the difference shows. |
| The dock opening no longer lines up | The cut-out sits off-center and the cable no longer seats squarely, after the trim was refitted crooked or over the wrong bracket position. |
| Bezel missing, loose, or lifting at one end | This bezel sits over the metal retaining bracket, so trim that will not stay down is often a bracket that was not re-seated or whose corner arms were bent during an earlier opening. If the whole end of the case is lifting instead, read the battery row in the table below first. |
Not every buyer here is fixing damage: restoring clean white trim after another repair, bringing a gift or keepsake iPod back to presentable condition, and finishing a refreshed shell while the case is already open are just as common. The bezel is white on all four case colors — Silver, Blue, Pink, Green — so there is no color to match; what you match is the model and which end of the tube the trim belongs to.
Do Not Buy / Problems This Housing Part Does Not Fix
| Situation | Start here instead |
|---|---|
| You have a full-size hard-drive iPod with a different case design. | This is a different model — check your order number and generation before ordering. |
| The only problem is an internal electronic symptom with no physical damage to this part | Start with the diagnosis that matches your symptom — not a housing part. |
| The issue is charging, audio, storage, display, or controls rather than fit, finish, or visible housing damage | Start with the hard drive, flash storage, or drive cable check. |
| It will not charge or sync, or the computer does not see it | Computer does not see it? See the sync FAQ on the microdrive or refurbished pages — start with the microdrive (4GB) or microdrive (6GB) page. Bent or corroded pins are on the 30-pin port itself, which is part of the logic board on this model; the metal bracket only locates it and this bezel only frames its opening. |
| The trim will not sit down, or the shell will not close flat | On this model the battery lies behind the display, so a pack that has swollen bows the internal stack, lifts the trim and can leave a dark pressure mark on the screen. New trim will not hold a swollen pack flat — start on the battery page. |
| The replacement would not match the model-specific fitment, color, or capacity family you are repairing | Confirm the exact model, capacity, connector, and case variant before ordering. |
Install Overview
Before You Start
Set Hold to locked (orange bar visible) before opening. Confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Reseat nearby ribbons and connectors before blaming a replacement housing part.
Confirm thickness, color, screw points, and nearby hardware alignment before pressing the case fully closed.
Repair steps
Documented repair-procedure steps for replacing the housing part on this model (from teardown guides; confirm against your unit before starting):
- Carefully insert a small flathead screwdriver or Jimmy in the seam between the metal casing and white plastic bottom. Use the screwdriver to pry up the white plastic bottom bezel. Be careful not to damage the soft plastic with your screwdriver.
- Carefully slide the iPod out of its casing by pushing on the logic board near the bottom edge of the click wheel.
Disassembly Guide
Disassembly guide summary: iPod Mini Bottom Bezel Replacement.
Show all 3 installation steps
Carefully slide a small flathead screwdriver or Jimmy into the seam between the metal casing and white plastic bottom. Lever up the white bottom bezel, taking care not to damage the soft plastic.
A small pair of snap-ring pliers is the best tool to take out the metal retaining bracket. You can also lever out the metal retaining bracket beneath the bottom bezel with a flathead screwdriver. Release the bracket by pressing in the corner metal arms first.
Lift the released bracket away and set it aside.
Product-specific placement, reassembly, and check
- Prepare and access. Confirm the exact model and listing fit first. Use the existing steps as a disassembly guide, gather the specified tools, disconnect power where applicable, and keep screws and cable positions organized.
- Place Replacement Plastic Dock Port Bezel. Transfer only the components required by the existing access steps, then align the listed cosmetic or structural part with its clips, openings, and edges.
- Reassemble without force. Reverse only the access steps needed for this repair, keep cables clear of case edges and screw posts, and close clips in stages.
- Validate before final closure. Before final closure, confirm an even fit and verify that buttons, switches, ports, display, and wheel movement remain unobstructed.
Stop condition: Stop if a connector, latch, screw, clip, housing edge, or the replacement part resists normal alignment. Recheck model fit, orientation, cable routing, and trapped hardware instead of forcing it.
After This Repair
| Check | What to do |
|---|---|
| Check trim fit | Confirm the trim sits flush and the port or opening is centered before final closure. |
| Still not fitting cleanly? | Recheck model-specific fitment, screw seating, and nearby clips before forcing the trim into place. |
Worth Knowing
- Bottom bezel houses the dock connector port opening.
- Removal required to slide internal components out of the aluminum tube.
- This is the second-generation (Mini 2nd Generation) bottom-bezel listing — sold as a single bezel with the pry tool included, not a multi-part kit.
- The bezel is white on every case color — Silver, Blue, Pink and Green — so there is no color to match; what you match is the model and which end of the tube the trim belongs to.
- The bottom bezel fits either iPod mini generation. Both minis use the same A1051 case and the same white trim, and replacement bezels are listed for the first and second generation alike by two independent sellers. The trim is not the only mini part that carries over, but three parts do not: the click wheel (its connectors are a different size), the display and the logic board — keep those with the iPod they came from.
- Under this bezel sits the metal retaining bracket that locates the dock port; it is a separate part and is not included here.
Frequently Asked Questions
How do I choose the right cosmetic part?
Match the model generation first, then confirm capacity 4GB / 6GB and that you need the bottom dock bezel rather than the top headphone bezel. The bezel is white on all four case colors — Silver, Blue, Pink, Green — so there is no color to match.
Is this for a full-size hard-drive iPod?
The iPod mini is a separate Apple product line from full-size hard-drive iPods. This is the iPod mini 2nd Generation.
Will this fix internal electronics symptoms?
No. Housing and trim parts are for fit, finish, color, alignment, or visible damage. Diagnose power, storage, audio, screen, and control faults separately.
How do I confirm this is the right exterior part?
Match the exact iPod Mini 2nd Generation model, visible part shape, color or finish goal, and any capacity or model-specific fitment note before ordering Replacement Plastic Dock Port Bezel.
Will this bezel fit a first-generation iPod mini?
Yes. Both mini generations use the same A1051 case and the same white trim, and replacement bezels are listed for the first and second generation alike. The trim carries over; three parts do not — the click wheel (its connectors are a different size), the display and the logic board — keep those with the iPod they came from.
