Replacement white front panel for iPod 2nd Generation A1019 / iPod (Touch Wheel). Use it when the front housing, display window, or Touch Wheel opening is cracked, scratched, broken, yellowed, brittle, warped, or missing; it fits 10GB / 20GB Touch Wheel models.
Product Overview
Choose this front panel listing to restore the visible fit, finish, or mounting hardware on the iPod 2nd Generation.
Use the Compatible Variants table below to confirm capacity, color, case, or order-number fitment.
This is a fit-and-finish part, so choose it by physical damage, color, case thickness, and missing hardware rather than by an electrical symptom.
What Is Included
Quick Buying Check
Buy this when
- Use this listing when the original front panel (white) is damaged, missing, mismatched, or physically worn; diagnose internal symptoms separately.
- The original front housing is cracked, broken, scratched, yellowed, brittle, missing, or cosmetically worn.
- The model, color, order number, and front-panel openings match this listing.
Diagnose first when
- Confirm the capacity match before ordering: 10GB, 20GB.
- Confirm the 2G Touch Wheel white front-panel layout before ordering.
- Confirm the capacity, case depth, and order number before ordering.
Dents or bent metal
Bent housings can affect fitment and reassembly, especially near clips, seams, and connector openings.
Loose fit or rattle
Loose front panels can point to worn clips or distorted edges; match the correct generation and front panel color before ordering.
General wear
Confirm visible wear, product family, and fitment before ordering.
What Brings People Here
Cosmetic refresh
Replace a scratched, worn, or damaged exterior to restore the iPod's appearance.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | A1019 |
| EMC | EMC 1942 |
| Condition | Used — factory original Apple part. Normal cosmetic wear expected. |
| Color | White |
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| M8737LL/A | 10GB | White | Shared front panel | Yes | — |
| M8740LL/A | 10GB | White | Shared front panel | Yes | — |
| M8738LL/A | 20GB | White | Shared front panel | Yes | — |
| M8741LL/A | 20GB | White | Shared front panel | Yes | — |
is not compatible with
- iPod 1st Generation - different front panel layout for the mechanical scroll wheel
- iPod 3rd Generation - different front panel design with separate touch buttons above the wheel
- iPod 4th Generation and later - different integrated-button wheel opening
- iPod touch 2nd Generation A1288 - different 2008 touchscreen iPod family
Cosmetic Failure Signs — When to Replace
This front panel is a cosmetic part — it does not change how the iPod plays, charges, or syncs. Replace it when the damage is physical:
Not every buyer here is fixing damage: matching the original white finish after another repair, restoring a gift or keepsake iPod to clean condition, and finishing a refreshed shell while the case is already open are just as common.
Do Not Buy This Front Panel Yet If...
| Situation | Start here instead |
|---|---|
| Variant or capacity does not match this listing | This is a different model — check your order number and generation before ordering. |
| You see a folder icon, clicking noise, or restore failure | Confirm restore behavior, storage fit, and setup state before ordering this part. |
| A symptom points to a different part | Start with battery for power/runtime symptoms; hard-drive cable for folder, clicking, or restore symptoms; LCD screen for display-only symptoms; FireWire port for FireWire sync or charge-port symptoms; touch wheel for touch-wheel or control symptoms; logic board for board-side damage or multi-system symptoms before buying this part. |
| Only the screen is affected and everything else works | Check the display path and ribbon seating before replacing this part. |
Install Overview
Before You Start
Turn Hold off, use the reset sequence for this generation, and confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Reseat nearby ribbons and connectors before blaming a replacement front panel.
Confirm thickness, color, screw points, and nearby hardware alignment before pressing the case fully closed.
Repair steps
Documented repair-procedure steps for replacing the front panel on this model (from teardown guides; confirm against your unit before starting):
- Lift the rear panel away from the iPod, making sure it doesn't catch on the headphone jack.
Repair Guide
Repair guide summary: iPod 2nd Generation Front Panel Replacement.
Show all 18 installation steps
Confirm that the hold switch is locked before you open the iPod.
Opening this iPod may take a few tries, which is normal for this case design. Slide a plastic opening tool into the seam where the white front panel meets the metal rear case. After the tool is seated, run it along the seam to release the five retaining tabs.
Slide the opening tool around the case edge until the five tabs release.
Work around the corner of the iPod and release the two tabs near the FireWire port.
Release the five tabs along the opposite side. Gently rocking the front panel back and forth can help free them.
Raise the back panel away from the device, making sure it doesn't catch on the headphone jack.
Peel up and back the metallic tape attached to the battery top.
Raise the battery away from the hard drive and set it next to the iPod; it remains connected to the logic board.
Carefully detach the orange ribbon cable from the hard drive. In this step, if the cable doesn't come free easily, it may be useful to gently wiggle the cable from side to side. Raise the hard drive out of the iPod.
For the next step, shift the locking bar only about 2 mm. Too much force or travel will damage the connector. Pull the brown locking bar toward the hard drive cable with your fingertips to loosen the connector.
Move the hard drive cable out of its connector.
Raise the blue hard drive mounting bracket out of the iPod.
Carefully detach the white battery connector from the logic board. Pull only on the connector housing, not the cables.
As with the hard drive connector, move this connector only about 2 mm in the next step. Pushing too hard or too far will damage it. Pull the brown locking bar toward the side of the iPod with your fingertips to loosen the touch wheel connector.
In this step, remove the 8 T6 Torx screws from the logic board.
Raise the logic board up enough to detach the orange touch wheel cable. Raise the logic board out of the iPod.
Raise the touch wheel out of the front panel.
Only the front panel remains.
After This Repair
| Check | What to do |
|---|---|
| Check the front fit | Confirm the white front housing sits flush and the display window and Touch Wheel opening are aligned. |
| Watch the plastic | Close the case without forcing brittle tabs or pinching the display, Touch Wheel, battery, or storage stack. |
| Still not fitting cleanly? | Reopen and check transferred hardware, tab alignment, and hidden plastic cracks before applying final pressure. |
Frequently Asked Questions
Can I mix colors or finishes?
No. The iPod 2nd Generation front panel is white only. Use a white 2G front housing for a stock repair; custom-color framing belongs to later models with actual color variants.
Does this include the touch wheel?
Check the individual SKU contents. This front-panel listing is for the outer white housing and display window; the touch wheel assembly is separate unless the listing explicitly includes it.
Does this fit both 10GB and 20GB iPod (Touch Wheel) models?
Yes. The same white front panel fits 10GB and 20GB A1019 Touch Wheel iPods. The rear backplate is the capacity-specific housing part.
How do I confirm this is the right exterior part?
Match the exact iPod 2nd Generation model, visible part shape, color or finish goal, and any capacity or case-depth note before ordering Replacement Front Panel (White).
Worth Knowing
- White only - no color variants for the 2G front panel.
- The same white front housing fits 10GB and 20GB A1019 iPod (Touch Wheel) models.
- The 2G Touch Wheel is touch-sensitive and does not rotate; the FireWire port cover is a key A1019 visual identifier.
Why people land on this part
Also searched as: iPod 2nd Generation white front housing, iPod 2nd Generation white front cover, iPod 2nd Generation white front shell, ipod 2nd generation front panel replacement, iPod 2g faceplate, iPod A1019 front panel, front panel iPod 2002, faceplate, iPod 2G front cover.
Symptoms people describe
- cracked ipod front panel
- scratched ipod front panel
- broken front panel
- broken faceplate
Fitment wording people compare
- bezel edge
- front frame
You May Also Want
Display is directly behind the front panel — inspect for scratches or cracks.
Related: Capacitive Touch WheelTouch wheel assembly attaches to the front panel.
Some buyers search for "dented" or "color match"; confirm the checks above point to this same part before ordering.
