Replacement chrome rear panel for the original iPod 1G 5GB / 10GB / 5GB Mac re-issue. Use it when the back cover is scratched, dented, bent, broken, or being matched to the correct rear capacity engraving. The 1G 5GB and 10GB panels share the same physical fit; choose the listing by engraving.
Product Overview
This rear panel listing covers Replacement Rear Panel (5GB) and its own connector path on the iPod 1st Generation.
Use the Compatible Variants table below to confirm capacity, color, case, or order-number fitment.
This is a fit-and-finish part, so choose it by physical damage, rear engraving, 1G generation fitment, order number, and missing hardware rather than by an electrical symptom.
Choose Your Option
This part comes in multiple variants. Confirm your iPod's capacity and order number before ordering.
Use the 5GB rear panel for 5GB 1G units only; match the engraved capacity and case fit.
You're viewing this optionWhat Is Included
Quick Buying Check
Buy this when
- Use this listing when the original rear panel (5GB) is damaged, missing, mismatched, or physically worn; diagnose internal symptoms separately.
- The model, rear engraving, capacity, and order number match this listing.
Diagnose first when
- Confirm the capacity, case depth, and order number before ordering.
- The problem is power, storage, FireWire, audio, display, or controls rather than visible rear-panel damage.
- The symptom started after opening the iPod and may be a disturbed internal cable or connector.
Do not buy for
- Do not use this part for: iPod 1st Generation 10GB rear panel if you want matching 10GB engraving — use the 10GB listing.
Dents, deep scratches, warped metal, or broken housing fit
Cracked, brittle, or broken exterior pieces are good reasons to replace the cosmetic or structural part.
Other Symptoms That May Involve This Part
| Symptom | What it means & what to check |
|---|---|
| No sound | This is an audio-path symptom. Check the headphone jack assembly first, then compare board-level audio only after jack checks fail. |
What Brings People Here
Cosmetic refresh
Replace a scratched, worn, or damaged exterior to restore the iPod's appearance.
Engraving removal
Choose a replacement rear housing when the goal is a cleaner back without prior engraving.
Specifications & Fitment
Part Details
| Detail | Value |
|---|---|
| Model Number | M8541 |
| EMC | EMC 1910 |
| Condition | Used — factory original Apple part. Normal cosmetic wear expected. |
| Material | Chrome stainless steel |
Compatible Variants
| Order Number | Capacity | Color | Case | Compatible | Notes |
|---|---|---|---|---|---|
| M8513LL/B | 5GB Mac re-issue | White | — | Yes— compatible | Stock match |
| M8513LL/A | 5GB | White | — | Yes | — |
| M8697LL/A | 5GB | White | — | Yes | — |
| M8709LL/A | 10GB | White | — | Yes— engraving will not match | Owner-verified: The 1G uses a single 0.78 in rear-shell profile for both capacities, so this 5GB-engraved backplate fits a 10GB unit — but the capacity engraving will not match your original. Use the 10GB listing for matching 10GB engraving. |
Cosmetic Failure Signs — When to Replace
This rear panel is a cosmetic part — it does not change how the iPod plays, charges, or syncs. Replace it when the damage is physical:
| Symptom | What it means & what to check |
|---|---|
| Dents and bent corners | Drop damage that keeps the polished back from sitting flush at the case seam. |
| Deep scratches and gouges | Hairline swirls are normal wear on a polished back; replace when scratches are deep enough to catch a fingernail. |
| Worn or unwanted engraving | A previous owner's engraving, or capacity text that no longer matches the build, reads wrong on an otherwise clean unit. |
| Loose fit after an earlier opening | A bent rim or clip from previous service keeps the seam from closing cleanly. |
Not every buyer here is fixing damage: matching the original white finish after another repair, restoring a gift or keepsake iPod to clean condition, and finishing a refreshed shell while the case is already open are just as common.
Do Not Buy This Rear Panel Yet If...
| Situation | Start here instead |
|---|---|
| Variant or capacity does not match this listing | Use the 10GB listing. |
| Liquid, corrosion, or board-side damage changes the diagnosis | Use this rear panel only when the visible fit, finish, or physical damage matches. |
| You see a folder icon, clicking noise, or restore failure | Confirm restore behavior, storage fit, and setup state before ordering this part. |
| A symptom points to a different part | Start with battery for power/runtime symptoms; hard-drive cable for folder, clicking, or restore symptoms; LCD screen for display-only symptoms; logic board for board-side damage or multi-system symptoms before buying this part. |
Start here instead
- 5GB engraving: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- chrome finish: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- flash upgrade: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod 1st generation back cover: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod Classic 1st Gen backplate: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod 1st generation M8513LL/A: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod 1st generation M8697LL/A: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod 1st generation hard drive replacement: use Replacement Hard Drive (5GB) first; this is a separate check, not a buy signal for this part.
- iPod 1st generation metal back: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod 1st generation shell replacement: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod classic 1st generation backplate: start with the matching nearby part path first; do not treat it as a buy signal for this part.
- iPod scroll wheel back cover: start with the matching nearby part path first; do not treat it as a buy signal for this part.
Install Overview
Before You Start
Set Hold to locked (orange bar visible) before opening. Confirm the model and variant before opening the iPod.
Treat case opening as the highest handling risk. Work around the seams gently and stop if the shell, clips, or internal stack resist.
Do not pull the halves apart or side-load board sockets. Reseat nearby ribbons and connectors before blaming a replacement rear panel.
Confirm thickness, color, screw points, and nearby hardware alignment before pressing the case fully closed.
Repair steps
Documented repair-procedure steps for replacing the rear panel on this model (from teardown guides; confirm against your unit before starting):
- Carefully disconnect the white battery connector from the logic board. Be sure to pull only on the connector itself and not on the cables.
- Insert a plastic iPod opening tool in the seam between the white plastic front and metal back of the iPod. It helps to hold the iPod at top and bottom and squeeze to help pop out the edge. Once you've inserted the tool, run it along the seam to free the five tabs holding the iPod together.
- Insert a plastic opening tool in the seam between the white plastic front and metal back. Hold the iPod at top and bottom and squeeze to help pop out the edge. Run the tool along the seam to free the five tabs.
Repair Guide
Repair guide summary: iPod 1st Generation Rear Panel Replacement.
Show all 5 installation steps
Confirm that the hold switch is set to the locked position before you begin opening the iPod.
Getting the iPod open may take several attempts — this is normal and expected. Slide a plastic opening tool into the gap where the white front panel meets the metal rear case. Holding the iPod at the top and bottom while squeezing helps pop the edge apart. Once the tool is in, run it along the seam to release the five retaining tabs.
Keep sliding the opening tool along the edge of the case until all five tabs on that side are free.
Move the tool around the corner and release the two tabs near the FireWire port area.
Release the five tabs along the opposite side. Gently rocking the front panel back and forth can help free them. Lift the rear panel away from the rest of the iPod.
After This Repair
| Check | What to do |
|---|---|
| Check rear alignment | Confirm the back cover sits flush with the front shell and does not pinch the battery, storage stack, or transferred hardware. |
| Verify engraving and fit | Make sure the rear engraving matches the intended 5GB or 10GB unit and that the clip line closes evenly before final pressure. |
| Still not fitting cleanly? | Reopen and check battery swelling, storage clearance, clip alignment, and screw points before forcing the case closed. |
Frequently Asked Questions
What is the difference between 5GB and 10GB back cover?
The only difference is the engraving on the back. The physical dimensions, material, and attachment mechanism are identical. A 5GB back cover will fit a 10GB iPod and vice versa, but the engraving will not match.
Is this an original Apple part?
This is an original Apple part. There are no aftermarket reproductions of the 1st generation iPod back cover. Every back cover available is a salvaged original.
How do I prevent scratches on the new back cover?
Apply a clear adhesive skin or film protector immediately after installation. The chromed stainless steel finish scratches easily and cannot be polished once the chrome layer is worn through.
Is this an iPod Classic?
Apple's 'Classic' branding started with the 6th Generation (2007). This is the iPod 1st Generation (2001), model M8541. Apple's official name for this model is iPod (Scroll Wheel).
Does a 2nd generation back cover fit the 1st generation?
No. The 1st and 2nd generation back covers are different dimensions. The 2nd generation iPod is slightly thinner, and the internal clip positions are different. They are not interchangeable.
Worth Knowing
- The 5GB rear panel is selected by rear capacity engraving, not by a separate 1G shell depth.
- 1G 5GB and 10GB rear panels share the same physical fit, but a sibling capacity will not match the engraving.
